E.Mosaic（Video Wall App）
--------------------------------------
E.9 In Width 960 960
E.10 In Height 540 540
E.11 In H_Start 0 0
E.12 In V_Start 0 0
E.13 Out Width 1920 1920
E.14 Out Height 1080 1080
E.15 Out H_Start 0 0
E.16 Out V_Start 0 0
LVP615U can maximally output 2304*1152 or customized resolution with
maximal horizontal 3840 pixels or vertical 1920 pixel. To drive such high
definition, LED display requires two transmission cards in cascade, so
LVP615U provides 2 positions for two built-in transmission cards.
If the actual definition of LED display exceeds the maximum output definition
of LVP615U, you may divide the whole LED screen into pieces of smaller LED
screens, then put them together in Mosaic manner by connecting multiple sets
of LVP615U in parallel to integrate the smaller pieces of LED screens into a
large LED display.
With frame synchronization technology, LVP615U solves the problems of
misplacement and delay of output image existing in ultra-large LED mosaic,
being able to provide real-time, clear and fluent display effects.
LVP615U supports multiple units cascading splicing. By this way, smaller
pieces of LED screens can be integrated into a large display. For example, if
the output definition of LVP615U is set as 1920×1080, and we put 2 sets of
LVP605 together horizontally in parallel, it will be able to connect any LED
display of up to 3840×1080 pixels.
There are 16 setup options in splicing setup menu, setup options 1-8 is
automatic splicing menu, 9-16 is fine adjustment, automatic setup menu is
used to input splicing screen’s parameters, in fine adjustment menu option
adjust parameters for outputting full picture.
Adjustment options
Descriptions
E.1 LED total width
The whole width and
height of LED screen
E.2 LED total height
E.3 unit width
The LED screen
resolution and position
E.4 unit height
