LVP615U
使用说明
50
In the menu E.8 auto Calculation, press OK, LVP615U starts to mosaic
automatically;
Observing image splicing effect. If any problem, enter fine adjustment menu
option E.9~E.16 to adjust image.
Below is a 2×2 mosaic example using 4 sets of LVP615U, telling us how to use
multi-units cascade of LVP615U and what we should pay attention to.
The definition of the LED screen is 3456×1920, we can divide it into the four
small pieces of LED of 1728×960 pixels as shown in figure below, each piece
of small LED screen is driven by a unit of LVP615U. With total 4 sets of
LVP615U, the 3456×1920 pixels LED screen is able to display a full picture.
