Model
Max. PV wire size
10A 4mm
2
/12AWG
20A 6mm
2
/10AWG
＊These are the maximum wire sizes that will fit the controller terminals.
CAUTION: When the PV modules connect in series, the open
circuit voltage of the PV array must not exceed 46V (XTRA**06)
at 25℃ environment temperature.
Battery and load wire size:
The battery and load wire size must conform to the rated
current, the reference size as below
:
Model
charge
current
discharge
current
Battery wire
size
Load wire
size
XTRA1206 10A 10A 4mm
2
/12AWG 4mm
2
/12AWG
XTRA2206 20A 20A 6mm
2
/10AWG 6mm
2
/10AWG
CAUTION: The wire size is only for reference. If there is a long
distance between the PV array and the controller or between
the controller and the battery, larger wires can be used to reduce the
voltage drop and improve performance.
CAUTION: For the battery, the recommended wire will be
selected according to the conditions that its terminals are not
connected to any additional inverter.
