4
1.4 PRODUCT CLASSIFICATION
Classify
Model
Display
Advanced
XTRA
XDS2
LED Indicators: PV & battery &
load working status
Buttons:
View or set the
parameters or clear the error
information.
LCD:
PV display:
voltage/current /generated
energy
/power
Battery display:
voltage/current/
temperature/capacity
Load display:
voltage/current/power
/consumed energy/load
working mode
