Vechline 1206 Series User Manual

25
The following rules must be observed when modifying the parameter values in User for
lithium battery.
-Over Voltage Disconnect Voltage>Over charging protection voltage (Protection Circuit
Modules(BMS))+0.2V
※
;
-Over Voltage Disconnect Voltage>Over Voltage Reconnect Voltage＝Charging Limit
Voltage ≥ Equalize Charging Voltage＝Boost Charging Voltage ≥ Float Charging
Voltage>Boost Reconnect Charging Voltage;
-Low Voltage Reconnect Voltage>Low Voltage Disconnect Voltage ≥ Discharging Limit
Voltage;
-Under Voltage Warning Reconnect Voltage>Under Voltage Warning Voltage≥
Discharging Limit Voltage;
-Boost Reconnect Charging voltage> Low Voltage Reconnect Voltage;
-Low Voltage Disconnect Voltage ≥ Over discharging protection voltage (BMS)+0.2V
※
.
WARNING: The voltage parameters of lithium battery can be set, but you must refer to the voltage
parameters of lithium battery BMS.
