Installation Guide Identifying Devices in the TLS RF Site Network
29
4. Repeat Steps 2 and 3 for each of the remaining transmitters. As you power up each of the remaining
transmitters and check their reception at the TLS RF, make notes on your site network worksheet as to
whether the transmitter signals are being received successfully, which one of the 8 red transmission
received LEDs in the TLS RF is flashing every 6 seconds, probe problems, etc., for later troubleshooting.
5. If each transmitter is being received at the TLS RF(s), go around to each transmitter, reconnect the
transmitter’s power cable to the battery, and replace the sump or dispenser cover as appropriate. Go to
the TLS console and configure all site probes and mag sump sensors. Check for any probe out/comm
alarms. If none are observed, the startup is complete.
If some transmitters are not being received at the TLS RF, you will have to install additional repeaters as
necessary. The repeater requires a Class 2, 15 Vdc power source.
