Veeder-Root TLS-350 PLUS Installation Manual

Appendix C: Device DIP Switch Settings Transmitter/Receiver/Repeater DIP Switch Settings
C-3
Figure C-3. S1:DIP switches 1-3
Figure C-4. Device ID Settings - S1:DIP switches 4-8
c-3.eps
1 2 3 900MHz Radio 869MHz Radio 900MHz Radio 869MHz Radio 900MHz Radio 869MHz Radio
OFF OFF OFF 30 30 Always Always Always Always
OFF OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
OFF ON OFF 60 60 Do Not Set Do Not Set Do Not Set Do Not Set
OFF ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON OFF OFF 10 10 Do Not Set Do Not Set Do Not Set Do Not Set
ON OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON ON OFF 240 240 Do Not Set Do Not Set Do Not Set Do Not Set
ON ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
1 2 3 900MHz Radio 869MHz Radio 900MHz Radio 869MHz Radio 900MHz Radio 869MHz Radio
OFF OFF OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
OFF OFF ON Australia Italy Australia Italy Australia Italy
OFF ON OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
OFF ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON OFF OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON OFF ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON ON OFF Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
ON ON ON Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set Do Not Set
RCVR
Version 1 (NA/EMEA)
Version 3 (Australia/Italy)
XMTR
RPTR
RCVR
S1: SW1-3
S1: SW1-3
XMTR: Diagnostic Time Out (Minutes)
RPTR
c-4.eps
45678
OFF OFF OFF OFF OFF
OFF OFF OFF OFF ON
OFF OFF OFF ON OFF
OFF OFF OFF ON ON
OFF OFF ON OFF OFF
OFF OFF ON OFF ON
OFF OFF ON ON OFF
OFF OFF ON ON ON
OFF ON OFF OFF OFF
OFF ON OFF OFF ON
OFF ON OFF ON OFF
OFF ON OFF ON ON
OFF ON ON OFF OFF
OFF ON ON OFF ON
OFFONONONOFF
OFFONONONON
ON OFF OFF OFF OFF
XMTR
RCVR
Version 1 and 3
Tank / Device Number
Do Not Set
(Unused)
Always
(Unused)
Always
S1: SW4~8
RPTR
1 (Master TLSRF Port 1)
2 (Master TLSRF Port 2)
3 (Master TLSRF Port 3)
4 (Master TLSRF Port 4)
5 (Master TLSRF Port 5)
6 (Master TLSRF Port 6)
7 (Master TLSRF Port 7)
8 (Master TLSRF Port 8)
9 (2nd TLSRF Port 1)
10 (2nd TLSRF Port 2)
11 (2nd TLSRF Port 3)
12 (2nd TLSRF Port 4)
13 (2nd TLSRF Port 5)
14 (2nd TLSRF Port 6)
15 (2nd TLSRF Port 7)
16 (2nd TLSRF Port 8)
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
Do Not Set
