ISD Alarm Message Diagnostics MISSING HOSE SETUP
20
MISSING HOSE SETUP
The Fuel Grade Table does not have any hoses assigned to it.
ISD MONITORING CATEGORY
ISD Setup Diagnostic self-tests (ref. page 17) are designed to monitor and ensure proper monitor configuration.
Setup self-test will verify at least one fuel position and gas hose is setup.
DIAGNOSTIC PROCEDURE
• This warning indicates the mapping of the hose devices to the dispensed products has not been started. Refer
to the ISD Setup manual (P/N 577013-800) to map hoses to the fuel products.
• The absence of this alarm does not mean the map is correct. The alarm indicates that the Fuel Grade Table has
no hoses assigned.
• Once all the hoses are mapped, enter and exit the Setup Menu using the MODE key, then press the red
ALARM button on the TLS and the condition should clear.
COMMON CAUSES
Hose mapping has not been started.
