Echo curve
Menu section, service
In this menu item you simulate a user-dened level or pressure
value via the current output. This allows you to test the signal
path, e.g. through connected indicating instruments or the
input card of the control system.
The following simulation variables are available:
l Percent
l Current
l Pressure (with pressure transmitters)
l Distance (with radar and guided microwave)
With Probus PA sensors, the selection of the simulated value
is made via the "Channel" in the menu "Basic adjustments".
How to start the simulation:
1 Push [OK]
2 Select the requested simulation variable with [->] and
conrm with [OK]
3 Set the requested value with [+] and [->].
4 Push [OK]
The simulation is now running, with 4 20 mA/HART a
current is outputted and with Probus PA or Foundation
Fieldbus a digital value.
How to interrupt the simulation:
à Push [ESC]
Information:
The simulation is terminated automatically 10 minutes after the
last key has been pushed.
Simulation
Start simulation?
With the reset function, modied values are reset. Three
subfunctions are available:
l Basic adjustment
Simulation of meas-
ured values
Reset
Indicating and adjustment module PLICSCOM 17
Setup
27835-EN-070123
