DCS value is represented by two words. T he first word
contains the real PC/DCS value, the next higher word the
corresponding status information. In the specification the term
register word is also used instead of word.
The filing of measured values in the temporary memory is
always sorted according to PC/DCS output number. The
following chart shows the addressing of the temporary memory
via Modbus.
Register address in
Modicon
Temporary memory of VEGAMET/PLICSRA-
DIO (1 word = 2 byte)
30001 PC/DCS output 1: Measured value
30002 PC/DCS output 1: Status
30003 PC/DCS output 2: Measured value
30004 PC/DCS output 2: Status
30005 PC/DCS output 3: Measured value
30006 PC/DCS output 3: Status
30007 PC/DCS output 4: Measured value
30008 PC/DCS output 4: Status
30009 PC/DCS output 5: Measured value
30010 PC/DCS output 5: Status
30011 PC/DCS output 6: Measured value
30012 PC/DCS output 6: Status
Register address in
Modicon
Temporary memory of VEGASCAN (1 word =
2 byte)
30001 PC/DCS output 1: Measured value
30002 PC/DCS output 1: Status
30003 PC/DCS output 2: Measured value
30004 PC/DCS output 2: Status
30005 PC/DCS output 3: Measured value
30006 PC/DCS output 3: Status
30007 PC/DCS output 4: Measured value
30008 PC/DCS output 4: Status
30009 PC/DCS output 5: Measured value
30010 PC/DCS output 5: Status
30011 PC/DCS output 6: Measured value
4 Modbus-TCP, VEGA ASCII protocol - VEGAMET 624/625, VEGASCAN 693, PLICSRADIO
Function as Modbus-TCP server
30768-EN-070730
