Veichi SI23 - Recommended Main Circuit Components Specification

SI23 Solar Pump VFD Manual
15
● Function Specification of Switch Terminals
Switch Terminal
Selecting Position
Function Specification
RS485 Terminal Resistor
RS485 Communication :connect with 120Ω terminal resistor
AO-F Output- frequency
0kHz～100kHz frequency output
AO-I Output- Current
0mA～20mA current output or 4mA～20mA current output
AO-U Output- Voltage
0V～10V voltage output
AI1 Input- Current/Voltage
AI1: Input 0mA～20mA or 0V～10V
AI2 Input- Current/Voltage
AI2: Input 0mA～20mA or 0V～10V
2.3 Recommended main circuit components specification
Model
Contactor Specification
Circuit Breaker Specification
SI23-D5-R75G-A
10A
10A
SI23-D5-1R5G-A
10A
10A
SI23-D5-2R2G-A
16A
15A
SI23-D5-004G-A
16A
20A
SI23-D5-5R5P-A
25A
20A
SI23-D5-5R5G-A
25A
20A
SI23-D5-7R5P-A
25A
30A
SI23-D5-7R5G-A
25A
30A
SI23-D5-011P-A
32A
40A
SI23-D5-011G-A
32A
40A
SI23-D5-015P-A
40A
50A
SI23-D5-015G-A
40A
50A
SI23-D5-018P-A
50A
60A
SI23-D5-018G-A
50A
60A
SI23-D5-022P-A
50A
75A
SI23-D5-022G-A
50A
75A
SI23-D5-030P-A
63A
100A
SI23-D5-030G-A
63A
100A
SI23-T3-037G-A
80A
125A
SI23-T3-045G-A
100A
150A
SI23-T3-055G-A
125A
175A
SI23-T3-075G-A
160A
200A
SI23-T3-090G-A
220A
250A
SI23-T3-110G-A
220A
300A
SI23-T3-132G-A
250A
400A
SI23-T3-160G-A
300A
500A
SI23-T3-185G-A
400A
600A
SI23-T3-200G-A
400A
700A
SI23-T3-220G-A
630A
800A
SI23-T3-250G-A
630A
1000A
SI23-T3-280G-A
630A
1200A
SI23-T3-315G-A
630A
1200A
SI23-T3-355G-A
800A
1400A
