Veichi SI23 - Functions, System Specs, and Environment

SI23 Solar Pump VFD Manual
5
Speed control
range
VC without PG: rated load 1:100; VC with PG: rated load 1:1000
Steady speed
accuracy
VC without PG: ≤2% rated synchronized speed; VC with PG: ≤0.05% rated
synchronized speed
Starting torque
VC without PG: 150% rated torque at 0.5Hz; VC with PG: 0Hz, 200% rated torque
at 0Hz
Torque response
VC without PG:<20ms; VC with PG: <10ms
Frequency
accuracy
Digital setting: max frequency× ± 0.01%; Analog setting: max frequency× ± 0.2%
Frequency
resolution
Digital setting: 0.01Hz; Analog setting: max frequency× 0.05%
Basic
functions
Torque control
Torque setting calculation, torque mode speed limit
DC braking
capacity
Starting frequency:0.00Hz～50.00Hz; Braking time:0.0s～60.0s; Braking
current:0.0～150.0% rated current
Torque boost
capacity
Automatic torque boost 0.0%～100.0%; Manual torque boost 0.0%～30.0%
V/F curve
Four modes: linear torque characteristic curve, self-set V/F curve, torque reduction
characteristic curve (1.1 to 2.0 power), square V/F curve
Acceleration/Decel
eration curve
2 modes: linear Acceleration/Deceleration and S curve Acceleration/Deceleration. 4
sets of ACC/DEC, time unit 0.01s selectable, longest time: 650.00s.
Rated output
voltage
Using the power supply voltage compensation function, the rated voltage of the
motor is 100%, which can be set within the range of 50 to 100% (the output cannot
exceed the input voltage).
Voltage
auto-adjustment
While power supply voltage fluctuates, it can auto-keep constant output voltage.
Auto
energy-saving
running
While under V/F control mode, according to load situation, auto-optimize output
voltage to save energy.
Auto-limit current
Auto-limit the current while running to prevent over current break trouble.
Instant power off
treatment
Uninterrupted operation through bus voltage control during instantaneous power loss.
Standard functions
PID control, speed track, power off restart, jump frequency, upper/lower frequency
limit control, program operation, multi- speed, RS485, analog output, frequency
impulse output.
Frequency setting
channels
Keyboard digital setting, Analog voltage/current terminal AI1, Analog voltage/current
terminal AI2, Communication given and multi-channel terminal selection, Main and
auxiliary channel combination, expansion card, supporting different modes switch.
Feedback input
channel
Voltage/Current Terminal AI1, Voltage/Current Terminal AI12, Communication given,
Low-speed pulse input PUL, extension card.
Running command
channel
Operation panel given, external terminal given, communication given, expansion
card given.
Input command
signal
Start, stop, FWD/REV, JOG, multi-step speed, free stop, reset, ACC/DEC time
selection, frequency given channel selection, external fault alarm.
External output
signal
1 relay output, 1 collector output, 1 AO output: 0V～10V output or 4mA～20mA
output.
Protection function
Overvoltage, under-voltage, current limit, over-current, overload, electric thermal
relay, overheat, overvoltage stall, data protection, rapid speed protection,
input/output phase failure protection.
Keyboard
display
LED display
Built-in keyboard: single line 5- digital tube
display
monitor 1 VFD status quantity
External keyboard: double line 5- digital tube
display
Monitor 2 VFD status quantities
