Features & specifications
When using one of our amplifiers (big or small), you always need a volume control and preferably also a tone
control. This kit comes complete with all input / output connections and potentiometers.
Furthermore it is possible to amplify or attenuate the input signal.
FEATURES:
stereo volume control
stereo Baxandall bass and treble control
bass and treble potentiometers with centre click
customizable attenuation or amplification
complete with knobs
SPECIFICATIONS:
supply voltage: 2 x 12VAC / 100mA
frequency response: 3Hz - 500kHz (-3dB)
standard amplification: x1
signal to noise ratio: 98dB
harmonic distortion: < 0.005% (@1KHz)
maximum output: 5V RMS
tone control:
+ and -15dB @ 20Hz
+ and -15dB @ 15kHz
Input impedance: 50k ohms
PCB dimensions: 105 x 70mm / 4,1 x 2,75"
modifications reserved
