7. Maintenance
7-20
ROBOT HP7C / HP10C / HP15C / HP17C
© VEMAG 2004
A return filter with a filter cartridge which can be changed is located on the
tank of the hydraulic drive.
• Remove the screw cap on the return filter (1) and replace the filter
cartridge.
• Then screw the screw cap back onto the filter
• Re-fit the housing cover.
7.10.2 Feed unit drive and feed unit seals
• Have the feed unit checked by VEMAG Customer Service and the feed
unit seals replaced.
1 Return filter
Fig. 7-23
Filter cartridge for return
filter
1
