INSTALLATION MANUAL
INSTALLATION
12
RECIRCULATION
COVER PLATE
SCREWS
NON-DUCTED INSTALLATION ONLY
7 ] Remove 3 screws retaining the recirculation cover plate to the hood. Discard this plate
with its screws. Peel off and discard the membrane covering the recirculation grille,
ensuring the openings are totally cleared.
