Installation and Operation Manual - HE275CF
ENGLISH
Installation
It is strongly recommended to wear gloves to complete the installation.
1. To use the air intake on the right side, remove the knockout by cutting the micro-joints. Cut and
remove the insulation and the other knockout inside the fireplace. To use the opening under the
fireplace, only cut the knockout.
2. Install the adapter included in the fireplace and align the notch of the adapter (T) with the one on
the fireplace. Turn the adapter clockwise.
T
Fresh air intake on the right side Fresh air intake underneath
3. If the air inlet installation is below the appliance, install the plate (F) with the supplied screw (G)
on the opening on the right side of the appliance. The plate (F) and screws (G) are in the user
manual.
