Installation and Operation Manual - HE275CF
ENGLISH
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 30898 ROUND WOODEN BLACK HANDLE DULL BLACK FINISH 1
2 30025 1/4-20 X 1/2" PAN-HEAD QUADREX BLACK SCREW 1
3 30187 STAINLESS WASHER ID 17/64" X OD 1/2" 2
4 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
5 SE24334 DOOR ASSEMBLY 1
6 SE72135 REPLACEMENT HANDLE WITH LATCH KIT 1
7 AC09185 DOOR LATCH KIT 1
8 AC06400 3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET 1
9 SE72341 VENTIS GLASS 1
10 AC01275 FIRESCREEN DOOR 1
11 SE72381 BOTTOM CAGE ASSEMBLY 1
12 PL72188 AIR INTAKE CLOSING PLATE 1
13 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A 3
14 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
15 PL72314 GLASS FRAME 2
16 30556 AIR CONTROL FINISHING TIP 1
17 30029 THREAD CUTTING SCREW 10-24 TYPE "F" X 3/8" HEX WASHER 2
18 SE72269 AIR CONTROL DAMPER ASSEMBLY 1
19 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
20 30060 THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC 1
21 PL72141 DECORATIVE ASH SHELF 1
22 30506 SCREW PAN TORX TYPE F 1/4-20 X 1" BLACK 5
23 SE72187 AIR TIGHT CHANNEL ASSEMBLY 1
24 30117 SOCKET SET SCREW #10-32 X 1/4" 2
25 30586 HINGE PIN 2
26 PL69151 ADAPTER 6" 1
27 44028 CERAMIC THERMODISC F110-20F 1
28 44142 BLOWER 6'' 300 CFM 1
29 49608 All stainlesss steel clamp 114 to 165 mm 4
30 AC01363 FORCED AIR KIT 1
31 PL72246 REAR SIDE SPACER 4
32 PL72245 SIDE SPACER 4
33 PL53065 REAR STANDOFF 2
34 PL72040 REFRACTORY PANEL BRACKET 2
35 30094 HEX SCREW WASHER HEAD 1/4-20 X 3/4" F ZINC TYPE 2
