SECTION C
OPERATION
VPI VENTRAC 3000 C-5
SEAT
Each VENTRAC 3000 has an adjustable seat — fore
and aft. Each operator should adjust the seat for the
greatest control and comfort. (Figure 12). Note: Seat
plate mounting hole options are available for
additional variables in seat positioning. The seat can
be tilted forward during nonuse for inspection and
servicing access. To tilt the seat forward, press down
on the back of the seat with one hand and push down
the front of the seat locking bracket with the other.
A prop bracket is attached to the seat plate to prop
the seat in the tilted position. The seat and seat plate
can be removed by disconnecting the two seat switch
wires, removing the cotter pin on the right, tilting the
seat to the steering wheel, and moving it slightly to
the left. (Figure 13)
OWNER’S MANUAL
Owner’s manual is located in tube under the right
rear fender directly behind the battery. Release hood
latches, tilt hood and remove top tube cover to access
manual (Figure 14).
Figure 12
Figure 13
Figure 14
