SECTION D
SERVICE & MAINTENANCE
VPI VENTRAC 3000 D-5
TOWING/FREE-WHEELING
Each transaxle is equipped with leverage to release
hydrostatic pumps for slow, level, short distance
towing. Both are located in the center pivot area of
the tractor. See (Figure 9 and 10). Each handle
needs to be pulled out a short distance and must be
secured in notch. Always release BOTH handles
when towing is complete! Failure to release one or
both handles creates a potential free-wheeling
hazard. Park brake is still operative in free-wheeling
mode but must be released in order to tow.
Figure 9—Right side
Front frame
Figure 10—Left side
Rear frame
