SECTION D
SERVICE & MAINTENANCE
VPI VENTRAC 3000 D-3
Hydrostatic Oil (Cont.)
Note: Activate attachment hydraulics full stroke in
both directions several times to purge the system of
air before replenishing oil in front transaxle
reservoir.
Hydraulic filter located behind the front right fender
(Figure 3) does not
need to be changed unless
serious or unusual contamination occurs to the
system. Contact dealer for further direction.
Note: Generally the hydrostatic oil level remains
constant except when:
1) New attachments are added that use the
auxiliary oil circuit. (front transaxle only)
2) There is an oil leak.
NOTE: Replacement of hydrostatic oil is
not recommended except in the
event of contamination.
When it is necessary to remove and/or replace the
battery, remove both cables. Then remove the front
or rear hold-down bracket (Figure 4). To install the
new battery, reverse the above instructions. Be sure
the new battery has the same dimensions, top
terminals, and is installed with the terminals on the
side toward the engine.
Transaxle capacity:
Approximately 1 gallon
BATTERY
Battery group—22 NF
Figure 3
Figure 4
