SERVICE
Service - 20
Lubrication
Always set the parking brake, shut o the tractor
engine, remove the ignition key, and ensure all
moving parts have stopped before checking
mower deck or blade condition, or attempting
any repair or adjustment.
Grease after every 50 hours of operation using
a lithium complex NLGI #2 grease. In very dirty,
sandy, or wet conditions, more frequent greasing
may be required.
Grease points, along with the recommended number
of pumps of grease, are shown on a decal located
on the underside of the deck shield. Refer to Figure
1 at the bottom of the page.
Gearbox
The gearbox uses 75W-140 synthetic gear oil. Gear
oil level should be maintained at the level of the
check port (A) on the rear or side of the gearbox.
A
Figure 1
