PARTS
Illustrated Parts - 29
Use only original Ventrac
replacement parts.
Carrier Frame
REF. PART NO. DESCRIPTION QTY.
1 .........62.1298 ....................FRAME, CARRIER MAIN - MJ840 (Serial # 1001-1803) ........................... 1
1 .........62.1424 ....................FRAME, CARRIER MAIN - MJ840 (Serial # 1804-) ............................... 1
2 .........62.1299 ....................FRAME, TIRE SWIVEL MJ ................................................. 2
3 .........50.0187 ....................SPINDLE, TIRE SWIVEL MJ ................................................ 4
4 .........53.0140 ....................WHEEL, ASM 9 X 3.5 X 4 FLATFREE ......................................... 4
5 .........99.B0057-2 .................WASHER, MACH 3/4 X 1-1/4 10 GA ZP ...................................... 12
6 .........55.0023 ....................BEARING, BALL .75 ID X 1.78 OD ........................................... 8
7 .........04.0013 ....................SNAP RING, INT .068 X 1.75 ................................................ 4
8 .........99.B0052 ...................SHIM, STEEL 3/4 X 1 X .062 ................................................ 4
9 .........53.0080 ....................DUST CAP, BEARING MOWER CASTER ..................................... 4
11 .........50.0055 ....................TUBE, AXLE-WHEEL LM ................................................... 4
12 ........99.A12NF ..................LOCKNUT, STOVER 3/4-16 SAE ............................................. 4
13 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 4
14 ........95.08 ......................WASHER, FLAT 1/2 SAE .................................................. 20
15 ........90.0812 ....................BOLT, 1/2-13 USS X 1 1/2 .................................................. 10
16 ........94.08 ......................WASHER, FLAT 1/2 USS ................................................... 4
17 ........95.06 ......................WASHER, FLAT 3/8 SAE .................................................. 16
18 ........90.0608 ....................BOLT, 3/8-16 USS X 1 ...................................................... 4
19 ........99.A08N ...................LOCKNUT, NYLON 1/2-13 USS ............................................. 10
20 ........90.0644 ....................BOLT, 3/8-16 USS X 5 1/2 ................................................... 4
21 ........99.A06N ...................LOCKNUT, NYLON 3/8-16 USS .............................................. 8
45 ........55.0071 ....................BEARING, 3/4 ROLLER 3.25” LONG ......................................... 1
46 ........55.0072 ....................BEARING, RETAINER 3/4” ................................................. 2
47 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 1
To Next Page
