PARTS
Illustrated Parts - 31
Use only original Ventrac
replacement parts.
Hitch Arms
REF. PART NO. DESCRIPTION QTY.
1 .........62.1296 ....................HITCH, ARM RIGHT - MJ840 ................................................ 1
2 .........62.1297 ....................HITCH, ARM LEFT - MJ840 ................................................. 1
3 .........42.0533 ....................LATCH, DECK PIVOT MJ ................................................... 1
4 .........64.1411 ....................BRACKET, DECK PIVOT LATCH MJ ......................................... 1
5 .........91.1020 ....................BOLT, 5/8-18 SAE X 2 1/2 ................................................... 2
6 .........95.10 ......................WASHER, FLAT 5/8 SAE ................................................... 2
7 .........90.0820 ....................BOLT, 1/2-13 USS X 2 1/2 ................................................... 2
8 .........99.SF08 ...................NUT, SRF 1/2-13 USS ...................................................... 4
9 .........06.0044 ....................CAP, PLASTIC 1/8 X 1/2 X 7/8 ............................................... 2
10 ........42.0450 ....................LINK, SPACING - LIFT ARMS ............................................... 1
11 .........04.0007 ....................RIVET, POP DOME 1/8 X 1/8 S.S. ............................................ 2
12 ........00.0217 ....................DECAL, WARNING READ OWNERS MANUAL ................................. 1
13 ........00.0220 ....................DECAL, GENERAL SAFETY ................................................ 1
14 ........00.0101 ....................DECAL, HAZARD-MOVING PART ........................................... 1
15 ........99.SF04 ...................NUT, SRF 1/4-20 USS ...................................................... 2
16 ........99.B0057-2 .................WASHER, MACH 3/4 X 1-1/4 10 GA ZP ....................................... 4
17 ........90.0408 ....................BOLT, 1/4-20 USS X 1 ...................................................... 1
18 ........99.A10NFN .................LOCKNUT, NYLON 5/8-18 SAE ZP ........................................... 2
19 ........95.05 ......................WASHER, FLAT 5/16 SAE .................................................. 4
20 ........90.0506 ....................BOLT, 5/16-18 USS X 3/4 ................................................... 4
21 ........99.SF05 ...................NUT, SRF 5/16-18 USS ..................................................... 2
22 ........41.0096 ....................SPRING, EXT 5/16 OD X 2-1/4 .............................................. 1
23 ........05.0118 ....................BUMPER, RUBBER CYLINDRICAL .......................................... 2
25 ........00.0100 ....................DECAL, MADE IN USA ..................................................... 1
26 ........00.0219 ....................DECAL, WARNING DO NOT REACH ......................................... 1
27 ........94.05 ......................WASHER, FLAT 5/16 USS .................................................. 4
28 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 2
To Next Page
