Ventrac MJ840 - Page 33

PARTS
Illustrated Parts - 33
Use only original Ventrac
replacement parts.
Drive Shaft & Gearbox
REF. PART NO. DESCRIPTION QTY.
1 .........87.0221 ....................GEARBOX ............................................................... 1
2 .........40.0354 ....................IDLER ARM, GEAR BOX MJ ................................................ 1
3 .........83.0013 ....................PULLEY, IDLER FLAT 3/8 X 3 1/2 ............................................ 1
4 .........42.0536 ....................SHAFT, DRIVE HITCH ARM MJ ............................................. 1
5 .........83.BK55H ..................PULLEY, 5.5” H-BUSHING .................................................. 1
6 .........83.BK45H ..................PULLEY, 4.5” H-BUSHING .................................................. 1
7 .........83.H16S ...................BUSHING, 1” SPLIT 1/4” KEY ............................................... 4
8 .........85.K0410 ...................KEY, 1/4 X 1-1/4 ........................................................... 4
9 .........95.06 ......................WASHER, FLAT 3/8 SAE (Serial # 1001-1447) .................................. 5
9 .........95.06 ......................WASHER, FLAT 3/8 SAE (Serial # 1448-) ...................................... 4
10 ........90.0614 ....................BOLT, 3/8-16 USS X 1 3/4 ................................................... 1
11 .........99.SF06 ...................NUT, SRF 3/8-16 USS ...................................................... 1
12 ........85.B0027 ...................BUSHING, 1/2 ID X 5/8 OD X 5/8 ............................................. 2
13 ........99.SF08 ...................NUT, SRF 1/2-13 USS ...................................................... 2
14 ........90.0824 ....................BOLT, 1/2-13 USS X 3 ...................................................... 1
15 ........83.BK60H ..................PULLEY, 6” H-BUSHING ................................................... 1
16 ........90.0406 ....................BOLT, 1/4-20 USS X 3/4 .................................................... 9
17 ........83.BK72H ..................PULLEY, 7.2” H-BUSH ..................................................... 1
18 ........55.FB16016-1 ...............BEARING, FLANGE BLOCK 1” .............................................. 2
19 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 2
20 ........99.SF05 ...................NUT, SRF 5/16-18 USS ..................................................... 4
21 ........99.E0046 ...................NUT, “U” 1/4-20 EXTRUDED ................................................ 1
22 ........60.1034 ....................SHIELD, DRIVE PULLEY - MJ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
23 ........81.B045 ....................BELT, B45 ............................................................... 1
24 ........41.0084 ....................SPRING, TORSION LH 1-3/16 IDX7 .......................................... 1
25 ........81.B045 ....................BELT, B45 ............................................................... 1
26 ........95.08 ......................WASHER, FLAT 1/2 SAE ................................................... 1
27 ........96.06 ......................WASHER, LOCK 3/8 ....................................................... 4
28 ........90.0608 ....................BOLT, 3/8-16 USS X 1 ...................................................... 4
30 ........99.SF0508 .................BOLT, SRF 5/16-18 USS X 1 ................................................ 4
31 ........06.0060 ....................CAP, VINYL 3/16 ID X 2 LONG .............................................. 1
32 ........96.04 ......................WASHER, LOCK 1/4 ....................................................... 1
33 ........95.04 ......................WASHER, FLAT 1/4 SAE ................................................... 1
34 ........99.G0014 ..................WASHER, 3/8 USS FW .165 THK (Serial # 1448-2355) ........................... 1
35 ........60.1056 ....................COVER, PULLEY (Serial # 1448-) ............................................ 1
50 ........23.0163 ....................VALVE, RELIEF ........................................................... 1
51 ........89.0094 ....................SEAL, SHAFT ............................................................ 2
52 ........55.0089 ....................BEARING, CUP SMALL .................................................... 1
53 ........55.0090 ....................BEARING, CONE SMALL .................................................. 1
54 ........55.0091 ....................BEARING, CUP LARGE .................................................... 3
55 ........55.0092 ....................BEARING, CONE LARGE .................................................. 3
56 ........89.0096 ....................GASKET, .005, FOR 87.0221 ............................................. A/R^
56 ........89.0097 ....................GASKET, .015, FOR 87.0221 ............................................. A/R^
56 ........89.0098 ....................GASKET, .003, FOR 87.0221 ............................................. A/R^
57 ........89.0099 ....................KIT, SEAL & GASKET FOR 87.0221 .......................................... 1
^ When replacing gaskets, measure the thickness of the gasket stack that was removed from the gearbox and replace
with a stack of equal thickness.
