Ventrac MJ840 - Page 35

PARTS
Illustrated Parts - 35
Use only original Ventrac
replacement parts.
Deck Belts (Serial # 1001-1447)
REF. PART NO. DESCRIPTION QTY.
1 .........64.1412 ....................BRACKET, IDLER MOUNT ................................................. 1
2 .........83.0038 ....................PULLEY, V-IDLER 4-1/4 X 3/8 ID ............................................. 8
3 .........40.0355 ....................IDLER ARM, OUTER DECK MJ ............................................. 2
4 .........40.0353 ....................IDLER ARM, CENTER DECK MJ ............................................ 1
5 .........85.B0027 ...................BUSHING, 1/2 ID X 5/8 OD X 5/8 ............................................. 2
6 .........90.0612 ....................BOLT, 3/8-16 USS X 1 1/2 ................................................... 1
7 .........95.06 ......................WASHER, FLAT 3/8 SAE .................................................. 48
8 .........99.SF06 ...................NUT, SRF 3/8-16 USS ..................................................... 10
9 .........81.AA096 ..................BELT, AA96 .............................................................. 1
10 ........81.AA096 ..................BELT, AA96 .............................................................. 1
11 .........81.BB078 ..................BELT, BB78 .............................................................. 1
12 ........90.0614 ....................BOLT, 3/8-16 USS X 1 3/4 ................................................... 4
13 ........95.08 ......................WASHER, FLAT 1/2 SAE ................................................... 4
14 ........99.SF08 ...................NUT, SRF 1/2-13 USS ...................................................... 2
15 ........90.0824 ....................BOLT, 1/2-13 USS X 3 ...................................................... 1
16 ........90.0616 ....................BOLT, 3/8-16 USS X 2 ...................................................... 4
17 ........41.0084 ....................SPRING, TORSION LH 1-3/16 IDX7 .......................................... 2
18 ........41.0083 ....................SPRING, TORSION RH 1-3/16 IDX7 .......................................... 1
19 ........90.0820 ....................BOLT, 1/2-13 USS X 2 1/2 ................................................... 2
20 ........64.1415 ....................BUSHING, ANTI-SCALP/IDLER SS .......................................... 2
21 ........85.B0088 ...................BUSHING, 5/8 ID X 3/4 OD X 1/2 ............................................. 4
22 ........99.A08N ...................LOCKNUT, NYLON 1/2-13 USS .............................................. 2
23 ........64.1453 ....................BUSHING, BELT TENSIONER .............................................. 2
24 ........06.0060 ....................CAP, VINYL 3/16 ID X 2 LONG .............................................. 3
25 ........94.06 ......................WASHER, FLAT 3/8 USS ................................................... 2
26 ........94.07 ......................WASHER, FLAT 7/16 USS .................................................. 4
27 ........90.0618 ....................BOLT, 3/8-16 USS X 2 1/4 ................................................... 1
