PARTS
Illustrated Parts - 39
Use only original Ventrac
replacement parts.
Spindles
REF. PART NO. DESCRIPTION QTY.
1 .........87.0229 ....................SPINDLE, ASM RH 25MM AL ............................................... 3
2 .........87.0230 ....................SPINDLE, ASM LH 25MM AL ................................................ 3
3 .........83.0050 ....................PULLEY, 5-1/8, 25MM STR. BORE ........................................... 4
4 .........99.B0057-2 .................WASHER, MACH 3/4 X 1-1/4 10 GA ZP ....................................... 6
5 .........99.A12NF ..................LOCKNUT, STOVER 3/4-16 SAE ............................................. 6
6 .........99.E0082 ...................NUT, LOCKING FLANGE 3/8 - 16 ........................................... 24
7 .........90.0612 ....................BOLT, 3/8-16 USS X 1 1/2 .................................................. 24
8 .........83.0055 ....................PULLEY, 2BK50 25MM BORE ............................................... 2
9 .........64.1408 ....................BRACKET, SPINDLE MOUNT LEFT (Serial # 1001-2339) ......................... 1
9 .........64.1985 ....................BRACKET, SPINDLE MOUNT LEFT (Serial # 2340-) ............................. 1
10 ........95.06 ......................WASHER, FLAT 3/8 SAE .................................................. 24
11 .........64.1407 ....................BRACKET, SPINDLE MOUNT RIGHT (Serial # 1001-2339). . . . . . . . . . . . . . . . . . . . . . . . 1
11 .........64.1984 ....................BRACKET, SPINDLE MOUNT RIGHT (Serial # 2340-). . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
12 ........79.0079 ....................BLADE, 15.00X1/2 RH F LOWLIFT ........................................... 3
13 ........79.0080 ....................BLADE, 15.00X1/2 LH F LOWLIFT ........................................... 3
14 ........64.1409 ....................BRACKET, SPINDLE MOUNT CENTER (Serial # 1001-2059) ...................... 1
14 ........64.1902 ....................BRACKET, SPINDLE MOUNT CENTER (Serial # 2060-) .......................... 1
15 ........64.2002 ....................GUARD, SPINDLE/ANTI-STRING ........................................... 6
16 ........91.0814-8L .................BOLT, 1/2-20 X 1 3/4 LH GR8 ................................................ 3
17 ........91.0814-8 ..................BOLT, 1/2-20 X 1 3/4 GR8 ................................................... 3
18 ........85.B0080 ...................BUSHING, 1-1/2 OD, 1 ID ................................................... 4
19 ........95.08 ......................WASHER, FLAT 1/2 SAE ................................................... 6
20 ........90.0608 ....................BOLT, 3/8-16 USS X 1 (Serial # 2060-) ......................................... 1
21 ........99.SF06 ...................NUT, SRF 3/8-16 USS (Serial # 2060-) ......................................... 1
30 ........29.GF0017 .................FITTING, RELIEF ......................................................... 1
31 ........87.0209-1 ..................HOUSING, SPINDLE AL ................................................... 1
32 ........55.0057 ....................BEARING, BALL 25 MM X 62 MM ............................................ 1
33 ........87.0208-2 ..................SHAFT, SPINDLE LH ...................................................... 1
34 ........55.0057 ....................BEARING, BALL 25 MM X 62 MM ............................................ 1
35 ........85.B0082 ...................BUSHING, SPINDLE SHAFT SPACER ....................................... 1
36 ........87.0210 ....................SPINDLE, FLANGE SHIELD ................................................ 1
37 ........85.W0406 ..................KEY, WOODRUFF 1/4 X 3/4 ................................................. 1
38 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 1
40 ........87.0209-1 ..................HOUSING, SPINDLE AL ................................................... 1
41 ........55.0057 ....................BEARING, BALL 25 MM X 62 MM ............................................ 1
42 ........87.0209-2 ..................SHAFT, SPINDLE RH ...................................................... 1
43 ........55.0057 ....................BEARING, BALL 25 MM X 62 MM ............................................ 1
44 ........85.B0082 ...................BUSHING, SPINDLE SHAFT SPACER ....................................... 1
45 ........87.0210 ....................SPINDLE, FLANGE SHIELD ................................................ 1
46 ........85.W0406 ..................KEY, WOODRUFF 1/4 X 3/4 ................................................. 1
47 ........29.GF0001 .................GREASE FTG, 1/4 SAE ST ................................................. 1
48 ........29.GF0017 .................FITTING, RELIEF ......................................................... 1
