PARTS
Illustrated Parts - 41
Use only original Ventrac
replacement parts.
Shields
REF. PART NO. DESCRIPTION QTY.
1 .........60.1028 ....................SHIELD, DECK RIGHT ..................................................... 1
2 .........60.1033 ....................SHIELD, CARRIER FRAME REAR ........................................... 1
3 .........60.1027 ....................SHIELD, DECK LEFT ...................................................... 1
4 .........44.0250 ....................SLIDE, SHIELD ........................................................... 2
5 .........60.1026 ....................SHIELD, CARRIER FRAME ................................................. 1
6 .........60.1032 ....................SHIELD, CARRIER FRAME LEFT ........................................... 1
7 .........99.E0046 ...................NUT, “U” 1/4-20 EXTRUDED ................................................ 4
8 .........47.0127 ....................LATCH, RUBBER DRAW T-HANDLE ......................................... 1
9 .........60.1029 ....................SHIELD, DECK HINGE RIGHT .............................................. 1
10 ........64.1413 ....................BRACKET, SHIELD SPRING ................................................ 3
11 .........90.0428 ....................BOLT, 1/4-20 USS X 3 1/2 ................................................... 3
12 ........41.0021 ....................SPRING, COMP 1/2 OD X 2-3/4 LG .......................................... 3
13 ........60.1030 ....................SHIELD, DECK HINGE LEFT ............................................... 1
14 ........95.04 ......................WASHER, FLAT 1/4 SAE .................................................. 18
15 ........90.0406 ....................BOLT, 1/4-20 USS X 3/4 .................................................... 9
16 ........60.1031 ....................SHIELD, CARRIER FRAME FRONT .......................................... 1
17 ........99.SF04 ...................NUT, SRF 1/4-20 USS ...................................................... 5
18 ........95.06 ......................WASHER, FLAT 3/8 SAE ................................................... 4
19 ........90.0628 ....................BOLT, 3/8-16 USS X 3 1/2 ................................................... 2
20 ........64.1410 ....................BUSHING, SHIELD MOUNT ................................................ 2
21 ........47.0213 ....................KNOB, 3/8-16 THRU HOLE ................................................. 2
22 ........06.0062* ...................TRIM, TRIM SEAL W/BULB X 2” ............................................. 1
23 ........06.0062* ...................TRIM, TRIM SEAL W/BULB X 5” ............................................. 3
24 ........06.0062* ...................TRIM, TRIM SEAL W/BULB X 7” ............................................. 3
25 ........00.0192 ....................DECAL, V-DECAL DIE CUT BLUE ........................................... 1
26 ........00.0062 ....................DECAL, DANGER SHIELD MISSING ......................................... 2
27 ........00.0261 ....................DECAL, MAINTENANCE MJ (Serial # 1001-1875) ............................... 1
27 ........00.0398 ....................DECAL, MAINTENANCE MJ (Serial # 1876-) ................................... 1
28 ........99.A04N ...................LOCKNUT, NYLON 1/4-20 .................................................. 3
29 ........99.SF06 ...................NUT, SRF 3/8-16 USS ...................................................... 2
30 ........99.K0072 ...................MACHINE SCREW, 10-24 X 1/2 ZP ........................................... 3
31 ........00.0189 ....................DECAL, VENTRAC ORBITAL ............................................... 1
32 ........99.K0105 ...................MACHINE SCREW, #10-32 X 3/8 ............................................. 4
33 ........05.0120 ....................BUMPER, NEOPRENE 10 GA - 1/4 ........................................... 4
34 ........96.04 ......................WASHER, LOCK 1/4 ....................................................... 4
