Ventrac MJ840 - Page 49

PARTS
Illustrated Parts - 49
Use only original Ventrac
replacement parts.
Deck Wing Lift Arms
REF. PART NO. DESCRIPTION QTY.
1 .........62.1300 ....................LIFT ARM, OUTSIDE DECK WING (Serial # 1001-1875) .......................... 2
1 .........62.1427 ....................LIFT ARM, OUTSIDE DECK WING (Serial # 1876-) .............................. 2
2 .........85.B0027 ...................BUSHING, 1/2 ID X 5/8 OD X 5/8 ............................................. 4
3 .........64.1406 ....................LIMITER, DECK HINGE UPPER ............................................. 2
4 .........64.1405 ....................LIMITER, DECK HINGE LOWER L ........................................... 1
5 .........64.1404 ....................PIN, LIFT ARM PIVOT ..................................................... 2
6 .........90.0816 ....................BOLT, 1/2-13 USS X 2 ...................................................... 2
7 .........99.SF08 ...................NUT, SRF 1/2-13 USS ...................................................... 4
8 .........95.08 ......................WASHER, FLAT 1/2 SAE ................................................... 6
9 .........99.SF05 ...................NUT, SRF 5/16-18 USS .................................................... 16
10 ........90.0508 ....................BOLT, 5/16-18 USS X 1 ..................................................... 8
11 .........90.0610 ....................BOLT, 3/8-16 USS X 1 1/4 ................................................... 4
12 ........99.SF06 ...................NUT, SRF 3/8-16 USS ...................................................... 8
13 ........41.0111 ....................SPRING, TORSION LH 1-3/16 ID X 7 ......................................... 2
14 ........95.04 ......................WASHER, FLAT 1/4 SAE ................................................... 2
15 ........90.0406 ....................BOLT, 1/4-20 USS X 3/4 .................................................... 2
16 ........99.SF04 ...................NUT, SRF 1/4-20 USS ...................................................... 2
17 ........45.0047 ....................CABLE, 1/8 X 12 SS W/3/8 LOOPS (Serial # 1001-2339) .......................... 4
17 ........45.0055 ....................CABLE, 1/8 X 12 SS STAMPED END (Serial # 2340-) ............................ 4
18 ........95.06 ......................WASHER, FLAT 3/8 SAE ................................................... 4
19 ........95.05 ......................WASHER, FLAT 5/16 SAE .................................................. 8
20 ........00.0218 ....................DECAL, WARNING PINCH POINT ........................................... 2
21 ........64.1405 ....................LIMITER, DECK HINGE LOWER (Serial # 1001-1221) ........................... 1
21 ........64.1658 ....................LIMITER, DECK HINGE LOWER R (Serial # 1222-) .............................. 1
