E - 9
SCREEN VIEWING ANGLE ADJUSTMENT
The Monitor is designed to allow users to have a comfortable viewing angle.
The viewing angle can be adjusted as top -12°~ +12°.
• Push screen frame to adjust viewing angle.
Caution:
• Do not force the screen frame over its maximum viewing angle settings as
stated above. Attempting this will result in damaging the unit.
POWER SUPPLY
Cautions:
• Use of an incorrect type AC adapter will damage the unit.
• Turn off the unit before unplugging the AC adapter from the unit so as to avoid the unit being damaged.
• To prevent electrical shock, match wide blade of plug to wide slot and fully insert.
• When the unit is not going to be used for long time, disconnect the AC power supply cord from the AC outlet.
AC adapter (EA10362)
Left side of unit
3
Power indicator
1
To DC IN 12V jack
2
To AC adapter
AC power cord
To AC outlet
A. Using the car plug adapter
The included 12V car plug adapter is
designed for use with vehicles that have
a 12V, negative ground electrical
system.
Cautions:
• Use this unit only with the included 12V car plug adapter, use with other car adapters could damage the system.
• The included 12V car plug adapter is for use with this unit only. Do not use them with other equipment.
• For interests of public safety, do not operate the unit or view video while driving the vehicle.
• Make sure the unit is secured correctly to prevent it from falling inside the vehicle in the event of an accident.
• When the inside of the 12V car socket is dirty with ashes or dust, the plug section may become hot due to poor
contact. Be sure to clean the 12V car socket before use.
• After use, disconnect the 12V car plug adapter from both the unit and 12V car socket.
B. Using the AC adapter (optional)
You can also power this unit by connecting an optional AC adapter.
Before you buy an AC Adapter, please note, the only AC adapter suitable for this unit is DC 12V 3.0A, with plus
center polarity
. Please check voltage & current (A) before buying an AC adapter.
12V car plug adapter
Left side of unit
1
To DC IN 12V jack
2
To the 12V car socket
