26 819.4496
Parts
Air Motor Parts List Fluid Section Parts List
Ref.
No.
Part No. Description Qty
1 819.4275 HOUSING, center; alum. 1
819.0247 HOUSING, center; stainless
steel
1
2 819.4276 COVER, air valve; alum. 1
819.0259 COVER, air valve; stainless steel 1
3 819.0221 SCREW, mach, hex flange hd;
M5 x 0.8; 12 mm
9
4
† 819.4278 GASKET, cover; Santoprene ® 1
5 819.4279 CARRIAGE; aluminum 1
6
† 819.4280 O-RING; nitrile 1
7
† 819.4281 BLOCK, air valve; acetal 1
8
 819.4282 PLATE, air valve; sst 1
9
† 819.4283 SEAL, valve plate; buna-N 1
10
† 819.4284 PACKING, u-cup; nitrile 2
11 819.4285 PISTON, actuator; acetal 2
12 819.4286 BEARING, piston; acetal 2
15 819.4287 BEARING, pin; acetal 2
16 819.4288 PIN, pilot; stainless steel 2
17
† 819.4289 O-RING; buna-N 2
18
† 819.4290 BLOCK, pilot; acetal 1
19 819.4291 BEARING, shaft; acetal 2
20 819.0220 SCREW, grounding 1
22 819.4294 GASKET, air cover; foam 2
23 819.4295 COVER, air; aluminum 2
819.7110 COVER, air; stainless steel 2
24 819.4296 SHAFT, diaphragm; sst 1
25 819.7051 SCREW; M8 x 1.25; 25 mm 12
Fluid
Section
Material
Ref.
No.
101 819.4497 COVER, fluid; 2
polypropylene
819.0279 COVER, fluid;
conductive
polypropylene
2
102 819.4498 MANIFOLD, inlet;
polypropylene
1
819.0278 MANIFOLD, inlet;
conductive
polypropylene
1
103 819.4499 MANIFOLD, outlet;
polypropylene
1
819.0288 MANIFOLD, outlet;
conductive
polypropylene
1
(P) or (C)
104 819.4301 PLATE, air side;
aluminum
2
105 819.4500 PLATE, fluid side;
polypropylene
2
106 819.4375 SCREW; M8 x 1.25;
70 mm; sst
8
107 819.4491 SCREW; M10 x
1.50;60 mm; sst
16
108 819.9753 SCREW; M10 x
1.50; 110 mm; sst
8
110
 819.6314 LABEL, warning 1
111 819.7000 MUFFLER 1
112 819.4377 SCREW; M8 x 1.25;
40 mm; sst
8
113 819.9758 WASHER; manifold;
outlet
4
114 819.9759 WASHER; manifold;
inlet
4
P
O
L
Y
P
R
O
P
Y
L
E
