VERDER VA 50 - Page 27

819.4496 27
Fluid Section Parts List (continued)
101 819.4501 COVER, fluid; PVDF 2
102 819.4502 MANIFOLD, inlet;
PVDF
1
103 819.4503 MANIFOLD, outlet;
PVDF
1
104 819.4301 PLATE, air side;
aluminum
2
105 819.4504 PLATE, fluid side;
PVDF
2
106 819.4375 SCREW; M8 x 1.25;
70 mm; sst
8
107 819.4491 SCREW; M10 x
1.50; 60 mm; sst
16
108 819.9753 SCREW; M10 x
1.50; 110 mm; sst
8
110
 819.6314 LABEL, warning 1
111 819.7000 MUFFLER 1
112 819.4377 SCREW; M8 x 1.25;
40 mm; sst
8
113 819.9758 WASHER; manifold;
outlet
4
114 819.9759 WASHER; manifold;
inlet
4
P
O
L
Y
-
V
I
N
Y
L
I
D
E
N
E
F
L
U
O
R
I
D
E
(K)
