10
ACTIVATE TIMER MODE
When using the timer mode, you must rst activate the timer mode:
With the thermostat turned on, hold the “M” button for 3 seconds.
You can select below settings:
00 = Override (disable timer functionality)
01 = Programmable. And the display will show “ ”.
Leave the thermostat and it will go back to normal displaying.
PROGRAMMING THE TIMER - Mode 01
When programming you need to select Programmable function and
the display must show “ ” (see above)
You can now set the heating programs. The thermostat must have
4 heating periods for the weekdays and 4 heating periods for the
weekend.
Please notice that the programming of the whole calendar week
must take place in one continuous process, so it is a good idea to
have the periods written down for reference when programming
the thermostat.
Note, for the weekend you will also need to program 2 periods. You
can choose one of the periods to be very short or in extension of
the other.
Timer functionality
EN
