VeriFone VX 520 GPRS CTLS User Manual

TERMINAL SETUP
Privacy Shield (Optional)
VX 520 GPRS CTLS I
NSTALLATION GUIDE 27
V
E
R
I
F
O
N
E
C
O
N
F
I
DE
N
T
I
A
L
TE
M
P
L
ATE
R
EV
F
6 Plug the AC power cord into a wall outlet or powered surge protector.
When the terminal has power, the terminal lights are activated and the LED
indicator remains lit.
If an application is loaded in the terminal, it starts after the initial VeriFone
copyright screen and usually displays a unique copyright screen. If no application
is loaded in the terminal,
DOWNLOAD NEEDED appears on screen after the initial
VeriFone copyright screen.
Privacy Shield
(Optional)
The privacy shield protects the customers’ PIN entry from being seen by the
cashier or other customers. The illustration (Figure 16) shows an example of a
VX 520 GPRS CTLS
with the optional privacy shield.
Figure 16 Optional Privacy Shield
WARNING
Do not plug the power pack into an outdoor outlet or operate the terminal
outdoors.
Disconnecting the power during a transaction may cause transaction data files
not yet stored in terminal memory to be lost.
To protect against possible damage caused by lightning strikes and electrical
surges, consider installing a power surge protector.
NOTE
Merchants who install the terminal without the privacy shield must ensure the
cardholder’s privacy when entering his PIN by positioning the terminal away from
open view.

VeriFone VX 520 GPRS CTLS Specifications

General

Brand	VeriFone
Model	VX 520 GPRS CTLS
Category	Payment terminals
Language	English
