STAGEMAKER® LINE
GUIDE TECHNIQUE
TECHNICAL GUIDE
Page 29
VERLINDE se réserve le droit de modifier sans préavis les caractéristiques de son matériel
VERLINDE reserve the right to modify or improve equipment described in this document
11/2008 VESAFR/GBSM04A
Capacité Type Vitesse Brins Chaîne Puissance In Id
Capacity Type Speed Falls Chain Power In Id
(kg) E m/min Ft /min KW A A
250 SM5 254M2-E 4 16 1 4.8x12.5 0.4 1.3 3.3
250 SM5 258M2-E 8 32 1 4.8x12.5 0.8 2.6 9
250 SM5 2516M1-E 16 64 1 4.8x12.5 0.8 2.6 9
500 SM5 504M1-E 4 16 1 4.8x12.5 0.4 1.3 3.3
500 SM5 508M1-E 8 32 1 4.8x12.5 0.8 2.6 9
500 SM10 516 M1-E 16 64 1 6,8X17,8 1.75 3.4 16
1000 SM10 1004 M1-E 4 16 1 6,8X17,8 0.9 2.3 11
1000 SM10 1008 M1-E 8 32 1 6,8X17,8 1.75 3.4 16
2000 SM10 2002 M1-E 2 8 2 6,8X17,8 0.9 2.3 11
2000 SM10 2004 M1-E 4 16 2 6,8X17,8 1.75 3.4 16
2000 SM20 2008B1-E 8/2 32/8 1 11.3x31 3.5/0.9 7.4/3.7 31/8.3
2500 SM25 2506B1-E 6.3/1.6 25/6 1 11.3x31 3.5/0.9 7.4/3.7 31/8.3
5000 SM25 5003B1-E 3.25/0.8 12.5/3 2 11.3x31 3.5/0.9 7.4/3.7 31/8.3
400Vac/50Hz values – ft/min. at 60Hz.
Capacité Type Vitesse Moteur
Motor
Reduction
carter
Capacity Type Speed
Poles Rpm
Gear ratio
(kg) E m/min ft/min Poles Tr/min
250 SM5 254M2-E 4 16 4 1390 43.19
250 SM5 258M2-E 8 32 2 2780 43.19
250 SM5 2516M1-E 16 64 2 2780 21.29
500 SM5 504M1-E 4 16 4 1390 43.19
500 SM5 508M1-E 8 32 2 2780 43.19
500 SM10 516 M1-E 16 64 2 2780 31.9
1000 SM10 1004 M1-E 4 16 4 1390 58.3
1000 SM10 1008 M1-E 8 32 2 2780 58.3
2000 SM10 2002 M1-E 2 8 4 1390 58.3
2000 SM10 2004 M1-E 4 16 2 2790 58.3
2000 SM20 2008B1-E 8/2 32/8 2/8 2710/635 112.99
2500 SM25 2506B1-E 6.3/1.6 25/6 2/8 2710/635 144.16
5000 SM25 5003B1-E 3.25/0.8 12.5/3 2/8 2710/635 144.16
400Vac/50Hz values – ft/min. at 60Hz.
