DISPLAY DESCRIPTION
1 SQL Sets the Squelch Level.
2 SCN List Select the “User” or “Dealer” Scan List.
3 BEEP Enables/Disables the Key Beeper.
4 BELL Enables/Disables the Bell function.
(alert tone activated by incoming subaudible CTCSS/DCS tone)
5 Lighting Enables/Disables the BUSY/TX LED.
6 Lock Set the Control Key Lockout Cofiguration (Key/PTT/Key+PTT).
7 Group Select the desired Channel Group.
8 SCAN Engages/Disengages Scanning (same as the programmable
[
SCAN
]
key).
9DW Engages/Disengages Dual Watch (same as the programmable
[
DW
]
key).
10 TA Engages/Disengages Talk Around (same as the programmable
[
TA
]
key).
11 Encrypt Enables/Disables the disabling the Encryption Unit temporarily.
ENB: Enables the disabling the Encryption Unit.
DIS: Disables the disabling the Encryption Unit.
12 AF MinVR Sets the minimum Audio Volume level.
13 Beep VR Sets the Beep Volume level.
14 Contrast Sets the LCD Contrast level.
15 Dimmer Sets the brightness of the backlighting of the key and LCD.
16 REC Mode Select the Recording mode.
ONE: Enables one-shot recording of audio for 120 seconds, with playback
from beginning of the message.
ROL: Enables rolling recording so long as the receiver is passing audio,
with playback of the last 120 seconds recorded.
17 Play Mode Set the priority system audio during recorder playback.
PLY: The recorded audio is higher priority than the received signals audio.
SIG: The received signal’s audio is higher priority than the playback audio.
USER SET MODE
The VX-4200 Series includes a “User Set” (Menu) Mode which allows the user to
define or configure various settings, such as Squelch, Display contrast, etc. To acti-
vate the “User Set” (Menu) Mode:
 Press the programmable key assigned to the “SET” function.
 Select the User Set Mode item you wish to change using the
[
P1
]
/
[
P2
]
keys,
then use the
[

]
/
[

]
keys to adjust the setting of the selected item.
 Press the
[
P1
]
or
[
P2
]
key to store the new configuration.
 Press
[
A
]
key to exit to normal operation.
Notes:
Menu items “16 REC Mode” and “17 PlayMode” will appear only when the optional Voice
Storage Unit is installed.
When Menu item “11 Encrypt” is set to “DIS” without having the optional Voice Scrambler
Unit installed, the encryption function will never be activated.
