VX-450 SerieS Operating Manual
12
°C). Charge out of this range could cause damage
to the battery pack.
5) Battery Pack shall not be exposed to excessive
heat such as sunshine, re, or the like.
6) Risk of explosion if battery is replaced by an in-
correct type. Dispose of used batteries according to
the instructions
7) For further details and cautions of the charging,
refer to the Operating Manual of the CD-58 Desk-
top Charger.
Battery Charging
(
CD-49/PA-45
)
r
Re fer rin g to Fig ure 1,
adjust the direction of the
Battery Holder of the
CD-
49
Desktop Charger in ac-
cordance with the battery
pack being charged; Push
in both sides of the Bat-
tery Holder while pulling
up on the Battery Holder
to remove it from the char-
ger base, select the correct
direction of the Battery
Ho lde r for t he batt ery
being charged, then replace the Battery Holder
by pressing down on both sides of the Battery
Holder, if necessary.
r
Referring to Figure 2, insert the DC plug from
the optional
PA-45
AC Adapter into the DC jack
on the rear panel of the
CD-49
Desktop Charger,
and then plug the
PA-45
AC Adapter into the AC
line outlet.
r
Insert the battery pack into the
CD-49
Desktop
Charger while aligning the slots of the battery
Before you BegIn
fIgure 1
Wide
Wide
CAUTION
Danger of explosion if battery is replaced
with an incorrect battery. Replace only with
the same or equivalent type.
To Next Page
