VX-820E SEriES OpErating Manual
Control & ConnECtors
(
4-KEy VErsion
)
VOL/PWR Knob
LED Indicator
Steady Red:
Transmitting in progress
Blinking Green:
Busy Channel
Steady Green:
Tone Squelch in defeated condition
Dealer Programmed Color
ø
Emergency, 5-Tone Decoded, or
2-Tone Decoded
CH
(
Channel
)
Selector
Antenna Jack
TOP SEL Key
Speaker
Microphone
PTT Switch
MONITOR Button
LAMP Button
MIC/SP Jack
(
External MIC/SP
)
LCD
(
Liquid Crystal Display
)
Battery Pack Latch 4-Button Programmable Key
ø
one of “Flashing in white”,
“Continuation changes
in sequential colors”, or
“Toggling the two colors”.
A B C D
