Vertex Standard VXR-7000 Service Manual

103VXR-7000 UHF Service Manual
CNTLUnit
Parts List
R 4271 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B b5
R 4272 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B b1
R 4273 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B c3
R 4274 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B b4
R 4275 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B b1
R 4276 CHIP RES. 270 1/10W 5% RMC1/10T 271J J24205271 1- B a4
R 4277 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b4
R 4278 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B c2
R 4279 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G4
R 4280 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B c2
R 4281 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 1- A G4
R 4282 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G4
R 4283 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B b2
R 4284 CHIP RES. 1 1/10W 5% RMC1/10T 1R0J J24205010 1- B a4
R 4285 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A G4
R 4286 CHIP RES. 4.7 1W 5% RMC1 4R7JTE J24305479 1- B a5
R 4287 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 4288 CHIP RES. 4.7 1W 5% RMC1 4R7JTE J24305479 1- B b5
R 4289 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B c2
R 4290 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B c2
R 4292 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f3
R 4293 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f3
R 4294 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F1
R 4295 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B h2
R 4296 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B4
R 4297 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B5
R 4298 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C5
R 4299 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B h2
R 4300 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A E2
R 4301 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e2
R 4302 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- A E3
R 4303 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- A E3
R 4304 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- A E3
R 4305 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- B d3
R 4306 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- B d3
R 4307 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B c3
R 4308 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B d3
R 4309 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B d3
R 4310 CHIP RES. 1.5M 1/16W 5% RMC1/16 155JATP J24185155 1- B d3
R 4311 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B d3
R 4312 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F3
R 4313 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 4314 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A F3
R 4315 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A G4
R 4316 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A G5
R 4318 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- B d2
R 4319 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A G1
R 4322 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c5
R 4401 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 4402 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 4403 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 4404 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 4405 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 4406 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
S 4001 SLIDE SWITCH SSSS21 N6090069 1- A G3
S 4002 SLIDE SWITCH SSSS21 N6090069 1- A G1
T 4001 AF TRANS. 12T01 L2190049 1- A H2
T 4002 AF TRANS. 12T01 L2190049 1- A H3
VR4001 POT. 100k EVN-5ESX50B15 J51811104 1-130 A D3
VR4001 POT. 100k EVM3VSX50B15 J51843104 131- A D3
VR4002 POT. 10k EVN-5ESX50B14 J51811103 1-130 A G3
VR4002 POT. 10k EVM3VSX50B14 J51843103 131- A G3
VR4003 POT. 10k EVN-5ESX50B14 J51811103 1-130 A G2
VR4003 POT. 10k EVM3VSX50B14 J51843103 131- A G2
X 4001 XTAL HC-49/S3 16MHz 16.000MHZ H0103174 1- A C4
X 4002 XTAL HC-49/4H 4.194304MHz 4.194304MHZ H0103081 1- A E5
HEAT SINK SP143K S5000217 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR

Vertex Standard VXR-7000 Specifications

General

Brand	Vertex Standard
Model	VXR-7000
Category	Repeater
Language	English
