102 VXR-7000 UHF Service Manual
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
R 4202 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B b5
R 4203 CHIP RES. 3.3M 1/16W 5% RMC1/16 335JATP J24185335 1- B c3
R 4204 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A F2
R 4205 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- A F3
R 4206 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F3
R 4207 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F3
R 4209 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F2
R 4210 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B c3
R 4211 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B c2
R 4212 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A G4
R 4214 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B c3
R 4215 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c4
R 4216 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A F2
R 4217 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- A F2
R 4218 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F4
R 4219 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- A F2
R 4220 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B c2
R 4221 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F3
R 4222 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F1
R 4223 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A F3
R 4224 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A F2
R 4225 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B c1
R 4226 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B c2
R 4227 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- B c3
R 4228 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- A G4
R 4229 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A G5
R 4230 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- B c3
R 4231 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F1
R 4232 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A F1
R 4233 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F1
R 4234 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- B c1
R 4235 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B c3
R 4236 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B b5
R 4237 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- A H1
R 4238 CHIP RES. 680 1/16W 5% RMC1/16 681JATP J24185681 1- B c1
R 4239 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A G2
R 4240 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a3
R 4241 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F2
R 4242 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- B c3
R 4243 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- A H4
R 4244 CHIP RES. 270k 1/16W 5% RMC1/16 274JATP J24185274 1- B a4
R 4245 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- A H3
R 4246 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A G4
R 4247 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c2
R 4248 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A G4
R 4249 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- B c1
R 4250 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- B c2
R 4251 CHIP RES. 270k 1/16W 5% RMC1/16 274JATP J24185274 1- B b4
R 4252 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- B c3
R 4253 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B b4
R 4254 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- A G3
R 4255 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B c2
R 4256 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B a3
R 4257 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- B b3
R 4258 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- A G4
R 4259 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A F1
R 4260 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G4
R 4261 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F1
R 4262 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 1- B a1
R 4263 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- B c3
R 4264 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b4
R 4265 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A G4
R 4266 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F2
R 4267 CHIP RES. 2.7 1/10W 5% RMC1/10T 2R7J J24205279 1- A H4
R 4268 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B c1
R 4269 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B a3
R 4270 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- B b1
