Vertex Standard VXR-7000 Service Manual

101VXR-7000 UHF Service Manual
CNTLUnit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
R 4136 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e2
R 4137 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e4
R 4138 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e1
R 4139 CHIP RES. 120k 1/16W 1% RMC1/16 124FTP J24183124 1- B e2
R 4140 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e4
R 4141 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- B e4
R 4142 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E2
R 4143 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B d4
R 4144 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c5
R 4145 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A F4
R 4147 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C5
R 4148 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c5
R 4149 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c6
R 4150 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e2
R 4151 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 1- B e2
R 4152 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4153 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B g5
R 4154 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B f5
R 4155 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1-21 B e2
R 4155 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 VERS. A 22- B e2
R 4155 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 VERS. BS1 62- B e2
R 4155 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 VERS. D 22- B e2
R 4156 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4157 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B d2
R 4158 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E1
R 4159 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D2
R 4160 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- A E2
R 4161 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e2
R 4162 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F3
R 4163 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F3
R 4164 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B e2
R 4165 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B c6
R 4166 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- B e2
R 4167 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F3
R 4168 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A F3
R 4169 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- A G5
R 4170 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B d2
R 4171 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D3
R 4172 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A F3
R 4173 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B d2
R 4174 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- B b5
R 4175 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4176 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4177 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A F3
R 4178 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A F3
R 4179 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A F3
R 4180 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F2
R 4181 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A G5
R 4182 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- A G5
R 4183 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4184 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4185 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4186 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 1- A G5
R 4187 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A F4
R 4188 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d3
R 4189 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d3
R 4190 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F3
R 4191 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d3
R 4192 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B c3
R 4193 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F2
R 4194 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B d3
R 4195 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- A F2
R 4196 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B d3
R 4197 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A G5
R 4198 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A F2
R 4199 CHIP RES. 270k 1/16W 5% RMC1/16 274JATP J24185274 1- B c3
R 4200 CHIP RES. 330k 1/16W 5% RMC1/16 334JATP J24185334 1- B c3
