Vertex Standard VXR-7000 Service Manual

100 VXR-7000 UHF Service Manual
CNTL Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
R 4065 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g2
R 4066 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f1
R 4067 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g2
R 4068 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- B g5
R 4069 CHIP RES. 470 1/16W 5% RMC1/16 471JATP J24185471 1- B g5
R 4070 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e3
R 4071 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4072 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g2
R 4073 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4074 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B g5
R 4075 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f1
R 4076 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B g5
R 4077 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B g5
R 4078 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A B4
R 4079 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f1
R 4080 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C4
R 4081 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C3
R 4082 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C3
R 4083 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C3
R 4084 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B d6
R 4085 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C3
R 4086 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B d6
R 4087 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B d5
R 4088 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f4
R 4089 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- B f4
R 4090 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A C4
R 4091 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A C4
R 4092 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B e1
R 4093 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e1
R 4094 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e1
R 4095 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D5
R 4096 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D5
R 4097 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4098 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D4
R 4099 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C5
R 4100 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B f3
R 4101 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A D2
R 4102 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E5
R 4103 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B d2
R 4104 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B d2
R 4105 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e2
R 4107 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A E5
R 4108 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e2
R 4109 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E5
R 4110 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A E5
R 4112 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 4113 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c4
R 4116 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A F4
R 4117 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B d2
R 4118 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B d2
R 4119 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B e1
R 4120 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A F5
R 4121 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B e2
R 4122 CHIP RES. 2.2M 1/16W 5% RMC1/16 225JATP J24185225 1- B c4
R 4123 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D2
R 4124 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B e1
R 4125 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A D4
R 4126 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B e2
R 4127 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B g5
R 4128 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d4
R 4129 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A F4
R 4130 CHIP RES. 330k 1/16W 5% RMC1/16 334JATP J24185334 1- B e4
R 4131 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e1
R 4132 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e1
R 4133 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A D2
R 4134 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- B e4
R 4135 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A F4
