Vertex Standard VXR-7000 Service Manual

99VXR-7000 UHF Service Manual
CNTLUnit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
Q 4039 TRANSISTOR DTA143XK T146 G3070032 1- A H1
Q 4040 IC NJM2904V-TE1 G1091677 1- A D4
Q 4041 PHOTO COUPLER TLP181(GB-TPR.F) G0090021 1-186 A H1
Q 4041 PHOTO COUPLER IS181GB G0090046 187- A H1
Q 4042 PHOTO COUPLER TLP181(GB-TPR.F) G0090021 1-186 A H3
Q 4042 PHOTO COUPLER IS181GB G0090046 187- A H3
Q 4043 IC TDA2003AHST G1090815 1- A H5
Q 4044 TRANSISTOR DTC144EK T146 G3070033 1- A G1
Q 4045 IC NJM2902V-TE1 G1091679 1- A E2
Q 4046 IC NJM2902V-TE1 G1091679 1- A E3
R 4001 CHIP RES. 4.7 1W 5% RMC1 4R7JTE J24305479 1- B h5
R 4002 CHIP RES. 47 1W 5% RMC1 470JTE J24305470 1- A A3
R 4003 CHIP RES. 47 1W 5% RMC1 470JTE J24305470 1- A A3
R 4004 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B g3
R 4005 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B2
R 4006 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B2
R 4007 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B2
R 4008 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B2
R 4011 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 1- A F2
R 4012 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g2
R 4013 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B g1
R 4015 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 4016 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 4017 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 4018 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 4019 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B1
R 4020 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B g3
R 4021 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e2
R 4025 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C2
R 4026 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B g3
R 4029 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A B2
R 4031 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B g2
R 4033 CHIP RES. 270k 1/16W 5% RMC1/16 274JATP J24185274 1- B f2
R 4034 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C1
R 4035 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1- A C2
R 4036 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A C1
R 4037 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B h1
R 4038 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B h4
R 4039 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 1-3 A C2
R 4039 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 4 A C2
R 4039 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 5-18 A C2
R 4039 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 VERS. A 19- A C2
R 4039 CHIP RES. 3.9k 1/16W 5% RMC1/16 392JATP J24185392 VERS. BS1 62- A C2
R 4039 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 VERS. D 19- A C2
R 4041 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g2
R 4042 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B h3
R 4043 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D1
R 4044 CHIP RES. 330 1/16W 1% RMC1/16 331FTP J24183331 1- A C1
R 4045 CHIP RES. 470 1/16W 1% RMC1/16 471FTP J24183471 1- A C1
R 4046 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C2
R 4047 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A2
R 4048 CHIP RES. 1k 1/16W 1% RMC1/16 102FTP J24183102 1- A C1
R 4049 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A C2
R 4051 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g2
R 4052 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A B4
R 4053 CHIP RES. 4.7k 1/16W 1% RMC1/16 472FTP J24183472 1- A C1
R 4054 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B f1
R 4055 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C2
R 4056 CHIP RES. 8.2k 1/16W 5% RMC1/16 822JATP J24185822 1- A C2
R 4057 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B g4
R 4058 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B h4
R 4059 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A C2
R 4060 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- B g3
R 4061 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- B f2
R 4062 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B f1
R 4063 CHIP RES. 470k 1/16W 1% RMC1/16 474FTP J24183474 1- B f1
R 4064 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B g3
