Vertex Standard VXR-7000 Service Manual

98 VXR-7000 UHF Service Manual
CNTL Unit
DESCRIPTION V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
 Please contact Vertes Standard LMR, Inc.
D 4036 DIODE DA3J101F0L G2071354 186- A D2
D 4037 DIODE MA143-(TX) G2070536 1-185 A D2
D 4037 DIODE DA3J101F0L G2071354 186- A D2
D 4040 DIODE DA204K T146 G2070388 1- B d3
F 4001 CHIP FUSE 3A F0805B3R00FWTR Q0000082 1-111 A C1
F 4001 CHIP FUSE 3.15A FHC20 322ADTP Q0000166 EIA (CE) 112- A C1
F 4001 CHIP FUSE 3A F0805B3R00FWTR Q0000082 Ex. EIA (CE) 112- A C1
F 4001 CHIP FUSE 3.15A FHC20 322ADTP Q0000166 124- A C1
J 4001 CONNECTOR B26B-PHDSS(LF)(SN) P0091239 1- A B1
J 4002 CONNECTOR SB20-08WS P0090615 1- A B3
J 4003 CONNECTOR SB20-14WS P0090656 1- A B6
J 4004 CONNECTOR SB20-06WS P0090613 1- A C1
J 4005 CONNECTOR SB20-06WS P0090613 1- A B5
J 4006 CONNECTOR SB20-15WS P0091093 1- A E6
J 4007 CONNECTOR SB20-14WS P0090656 1- A D1
J 4008 CONNECTOR SB20-13WS P0090620 1- A F1
J 4009 CONNECTOR B8B-PH-K-S(LF)(SN) P0090402 1- A I2
J 4010 CONNECTOR SB20-03WS P0090610 1- A H5
J 4011 CONNECTOR SB20-02WS P0090609 1- A H5
L 4006 M.RFC 2.7uH LK1608 2R7K-T L1690848 1- B g4
NF4001 EMI FILTER DSS706-351D221M25-50 Q9000642 1- A B1
NF4002 EMI FILTER DSS706-351D221M25-50 Q9000642 1- A B1
NF4003 EMI FILTER DSS706-351D221M25-50 Q9000642 1- A B1
NF4004 EMI FILTER DSS706-351D221M25-50 Q9000642 1- A B1
NF4005 EMI FILTER DSS706-351D221M25-50 Q9000642 1- A B2
Q 4001 IC UPC2409AHF G1092259 1-184 A A5
Q 4001 IC BA09CC0T G1095474 185- A A5
Q 4002 IC UPC78M05AHF G1092314 1-186 A A2
Q 4002 IC NJM78M05FA G1095461 187- A A2
Q 4003 TRANSISTOR DTC144EK T146 G3070033 1- B g3
Q 4004 IC AN8005M-(E1) G1091454 1- B h4
Q 4005 IC RH5VL45AA-T1 G1090966 1-159 A B4
Q 4005 IC R3111H451A-T1-F G1094764 160- A B4
Q 4006 TRANSISTOR FMG2 T148 G3070015 1- B h2
Q 4007 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A B3
Q 4008 IC NM93C86AM8(TAPING) G1092512 1-57 A C3
Q 4008 IC M93C86-WMN6T G1094101 58- A C3
Q 4009 TRANSISTOR FMG2 T148 G3070015 1- B f2
Q 4010 TRANSISTOR FMG2 T148 G3070015 1- B f1
Q 4011 TRANSISTOR FMG2 T148 G3070015 1- B d1
Q 4012 IC HD64F3337YF16(FLASH)  1- A C3
Q 4013 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B f4
Q 4014 IC NJM2902V-TE1 G1091679 1- A D2
Q 4015 IC M62354FP-75NC G1091842 1- A D2
Q 4016 IC NJM2902V-TE1 G1091679 1- A G4
Q 4017 IC LC73881M-TLM-E G1092755 1- B e5
Q 4018 IC NJM2902V-TE1 G1091679 1- A G2
Q 4019 IC NJM2902V-TE1 G1091679 1- A G1
Q 4020 IC NJM2902V-TE1 G1091679 1- A G3
Q 4021 IC NJM2902V-TE1 G1091679 1- A G5
Q 4022 IC TC74HC74AF EL G1091446 1- B f5
Q 4023 TRANSISTOR DTC144EK T146 G3070033 1- A F5
Q 4024 IC FX805LG-TR G1092528 1- A E4
Q 4025 IC FX803LG-TR G1093037 1- A F5
Q 4026 TRANSISTOR DTC323TK T146 G3070042 1- B c5
Q 4027 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A F3
Q 4028 TRANSISTOR FMG2 T148 G3070015 1- A F2
Q 4029 IC M51132FP 600C G1091930 1- A F2
Q 4030 IC NJU4066BV-TE1 G1091873 1- A F2
Q 4031 IC NJM2902V-TE1 G1091679 1- A C1
Q 4032 TRANSISTOR FMG2 T148 G3070015 1- A F3
Q 4033 IC NJM2902V-TE1 G1091679 1- A C2
Q 4034 IC NJM2902V-TE1 G1091679 1- A E2
Q 4035 TRANSISTOR DTC144EK T146 G3070033 1- A F3
Q 4036 TRANSISTOR DTC323TK T146 G3070042 1- A G4
Q 4037 TRANSISTOR DTC323TK T146 G3070042 1- B c3
Q 4038 TRANSISTOR DTC323TK T146 G3070042 1- A F4
