Vertex Standard VXR-7000 Service Manual

97VXR-7000 UHF Service Manual
CNTLUnit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
C 4259 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174822 1- A G2
C 4260 CHIP CAP. 0.0047uF 50V B ECJ1VB1H472K K22179622 1-128 A E2
C 4260 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 129- A E2
C 4261 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2
C 4263 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A E2
C 4265 CHIP CAP. 0.012uF 50V B GRM188B11H123KA01D K22174825 1- B d2
C 4266 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A E2
C 4267 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 1- A E3
C 4269 CHIP CAP. 0.033uF 16V B ECJ1VB1C333K K22129515 1-138 B d2
C 4269 CHIP CAP. 0.033uF 16V B GRM188B11C333KA01D K22124812 139- B d2
C 4270 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174827 1- A E2
C 4272 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e2
C 4273 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A E3
C 4274 CHIP CAP. 0.056uF 16V B GRM188B11C563KA01D K22124807 1- A E3
C 4275 CHIP CAP. 0.0027uF 50V B ECJ1VB1H272K K22179619 1-139 A E3
C 4275 CHIP CAP. 0.0027uF 50V B GRM188B11H272KA01D K22174814 140- A E3
C 4276 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d3
C 4277 CHIP CAP. 0.0018uF 50V B ECJ1VB1H182K K22179617 1-132 A F3
C 4277 CHIP CAP. 0.0018uF 50V B GRM188B11H182KA01D K22174812 133- A F3
C 4278 CHIP CAP. 0.056uF 16V B GRM188B11C563KA01D K22124807 1- B d3
C 4279 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B d4
C 4280 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d3
C 4281 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B d3
C 4282 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d4
C 4283 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d4
C 4284 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A E2
C 4285 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e2
C 4287 CHIP CAP. 0.033uF 16V B ECJ1VB1C333K K22129515 1-138
C 4287 CHIP CAP. 0.033uF 16V B GRM188B11C333KA01D K22124812 139-
D 4001 DIODE DA204K T146 G2070388 1- B h1
D 4002 DIODE DA204K T146 G2070388 1- B h1
D 4003 DIODE DA204K T146 G2070388 1- B h1
D 4004 DIODE DA204K T146 G2070388 1- B h1
D 4005 DIODE DA204K T146 G2070388 1- B h1
D 4006 DIODE DA204K T146 G2070388 1- A B2
D 4007 DIODE D1F20-5063 G2070474 1-109 B h3
D 4007 DIODE D1F60-5053 G2071240 110- B h3
D 4008 DIODE HZM7C-TR G2070070 1-40 B h3
D 4008 DIODE HZM7.5NB2 TR G2070864 41- B h3
D 4009 DIODE DA204K T146 G2070388 1- A B4
D 4010 DIODE 1SS355 TE-17 G2070470 1- B h4
D 4011 DIODE 1SS355 TE-17 G2070470 1- B h3
D 4012 DIODE DA204K T146 G2070388 1- A B5
D 4013 DIODE 1SS355 TE-17 G2070470 1- A B4
D 4014 DIODE 1SS355 TE-17 G2070470 1- B f1
D 4015 DIODE MA729-(TX) G2070320 1-158 B f4
D 4015 DIODE DB2J31300L G2071338 159- B f4
D 4016 DIODE DA204K T146 G2070388 1- A B5
D 4017 DIODE DA204K T146 G2070388 1- B e6
D 4018 DIODE DA204K T146 G2070388 1- B d5
D 4019 DIODE DA204K T146 G2070388 1- A F5
D 4020 DIODE DA204K T146 G2070388 1- A C5
D 4021 DIODE DA204K T146 G2070388 1- B e4
D 4022 DIODE DA204K T146 G2070388 1- A C5
D 4023 DIODE DA204K T146 G2070388 1- A C5
D 4024 DIODE DA204K T146 G2070388 1- B b3
D 4025 DIODE 1SS184 TE85R G2070009 1- B a3
D 4026 DIODE 1SS184 TE85R G2070009 1- B a2
D 4027 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H1
D 4028 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H3
D 4029 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A I1
D 4030 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H3
D 4031 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H2
D 4032 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H2
D 4033 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H2
D 4034 SURGE ABSORBER ERZ-V07D121 Q9000604 1- A H2
D 4036 DIODE MA143-(TX) G2070536 1-185 A D2
