96 VXR-7000 UHF Service Manual

CNTL Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR

Parts List

C 4194 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B c3

C 4195 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B c1

C 4196 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c2

C 4197 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- B b5

C 4198 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 4199 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A F2

C 4200 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- B c2

C 4201 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A G4

C 4202 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a3

C 4203 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B c4

C 4204 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c3

C 4205 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B c4

C 4206 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B b4

C 4207 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A H1

C 4208 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G4

C 4209 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174811 1- B b4

C 4210 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a3

C 4211 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- B c3

C 4212 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174822 1- B c3

C 4213 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A F2

C 4214 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c4

C 4215 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A G5

C 4216 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d1

C 4217 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c1

C 4219 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c1

C 4220 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c1

C 4221 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c1

C 4222 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B c4

C 4223 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B c1

C 4224 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A H4

C 4225 AL.ELECTRO.CAP. 10uF 35V RC2-35V100MD1#-F1 K40169025 1- A G2

C 4226 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B c2

C 4227 CHIP CAP. 0.0033uF 50V B GRM188B11H332KA01D K22174815 1- A I4

C 4228 CHIP CAP. 270pF 50V CH GRM1882C1H271JA01D K22174251 1- A G1

C 4229 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B c3

C 4230 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1-75 A H4

C 4230 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023

76-184

AH4

C 4230 AL.ELECTRO.CAP. 10uF 16V UWX1C100MCL2GB K48120016 185- A H4

C 4231 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B b4

C 4232 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a1

C 4233 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B c4

C 4234 CHIP CAP. 680pF 25V CH GRM39CH681J25PT K22144203 1- A G1

C 4235 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B c2

C 4236 CHIP CAP. 560pF 50V B ECUV1H561KBV K22179611 1-128 B b4

C 4236 CHIP CAP. 560pF 50V B GRM188B11H561KA01D K22174806 129- B b4

C 4237 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F2

C 4238 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B a2

C 4239 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a3

C 4240 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- B b5

C 4241 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F2

C 4242 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 4243 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B c3

C 4244 CHIP CAP. 0.0012uF 50V B GRM188B11H122KA01D K22174826 1- A G2

C 4245 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a3

C 4246 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B b4

C 4247 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A I4

C 4248 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B b4

C 4249 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A G2

C 4250 AL.ELECTRO.CAP. 10uF 35V RC2-35V100MD1#-F1 K40169025 1- A G3

C 4251 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- B a4

C 4252 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 1- A G2

C 4253 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 4254 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 4255 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a5

C 4256 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 4257 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 4258 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A H5
