Vertex Standard VXR-7000 Service Manual

109VXR-7000 UHF Service Manual
PCB with Components CS1686001
C 5001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b2
C 5002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f2
C 5003 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-107 B e1
C 5004 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-107 B e1
C 5004 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 108- B e1
C 5005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f2
C 5006 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-107 B d1
C 5006 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 108- B d1
C 5007 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-107 B d1
C 5008 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e2
C 5009 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e2
C 5010 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e2
C 5011 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D1
C 5012 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e2
C 5013 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d2
C 5014 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 5015 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 5016 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B f1
C 5017 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f2
C 5018 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f2
C 5019 CHIP TA.CAP. 10uF 25V TEESVD1E106M12R K78140018 1- B f2
C 5020 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d2
C 5021 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d2
C 5022 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d2
C 5023 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 108-
C 5024 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 108-
C 5025 CHIP CAP. 0.01uF 16V B ECUV1C103KBV K22129510 108-128
C 5025 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 129-
D 5001 LED GL8KG21 G2090625 1-107 A A2
D 5001 LED SLB-25MG G2090807 108- A A2
D 5002 LED GL8PR21 G2090395 1-107 A A1
D 5002 LED SLB-25VR G2090806 108- A A1
D 5003 DIODE MA143-(TX) G2070536 1-107 B b2
D 5003 DIODE DAN217U T106 G2071236 108- B b2
D 5004 DIODE DAN217U T106 G2071236 108- A E1
D 5005 DIODE MA143-(TX) G2070536 1-107 B e2
D 5005 DIODE DAN217U T106 G2071236 108- B e2
D 5006 DIODE MA143-(TX) G2070536 1-107 B e2
D 5006 DIODE DAN217U T106 G2071236 108- B e2
D 5007 DIODE MA143-(TX) G2070536 1-107 B e2
D 5007 DIODE DAN217U T106 G2071236 108- B e2
D 5008 DIODE MA143-(TX) G2070536 1-107 B e2
D 5008 DIODE DAN217U T106 G2071236 108- B e2
D 5009 DIODE MA143-(TX) G2070536 1-107 B f2
D 5009 DIODE DAN217U T106 G2071236 108- B f2
D 5010 DIODE MA143-(TX) G2070536 1-107 B e2
D 5010 DIODE DAN217U T106 G2071236 108- B e2
D 5011 DIODE MA143-(TX) G2070536 1-107 B e2
D 5011 DIODE DAN217U T106 G2071236 108- B e2
D 5012 LED HLMF-KL05 G2090692 1-107 A A1
D 5012 LED TLOU262(F) G2090763 108-160 AA1
D 5012 LED SLI-343DU3F G2090824 161- A A1
D 5013 LED HLMF-KL05 G2090692 1-107 A A2
D 5013 LED TLOU262(F) G2090763 108-160 AA2
D 5013 LED SLI-343DU3F G2090824 161- A A2
D 5014 DIODE MA143-(TX) G2070536 1-107 B d2
D 5014 DIODE DAN217U T106 G2071236 108- B d2
D 5015 DIODE MA143-(TX) G2070536 1-107 B e2
D 5015 DIODE DAN217U T106 G2071236 108- B e2
D 5016 DIODE MA143-(TX) G2070536 1-107 B b2
D 5016 DIODE DAN217U T106 G2071236 108- B b2
D 5017 DIODE MA143-(TX) G2070536 1-107 B b2
D 5017 DIODE DAN217U T106 G2071236 108- B b2
D 5018 DIODE MA143-(TX) G2070536 1-107 B b2
D 5018 DIODE DAN217U T106 G2071236 108- B b2
D 5019 DIODE MA729-(TX) G2070320 108-158
Display Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
