110 VXR-7000 UHF Service Manual
Display Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
D 5019 DIODE DB2J31300L G2071338 159-
DS5001 LCD TTR3165UPFDCW G6090134 1-59 A C1
DS5001 LCD A15A012X G6090159 60-169 AC1
DS5001 LCD GHG4346ST01 G6090226 170- A C1
DS5002 LED NAA261-B G2090745 1-107
DS5002 LED LB-602DA2 G2090779 108-
J 5001 CONNECTOR 12FMZ-BT(LF)(SN) P1090901 1-107 B e2
J 5002 CONNECTOR SB20-06WS P0090613 108-
JP5001 WIRE ASSY A1367+ T9206797A 1- B b1
L 5001 M.RFC 22uH FLC32T-220J L1690219 108-160
L 5001 M.RFC 22uH NLV32T-220J-EF L1691743 161-
Q 5001 IC DN8657S-E1V G1092688 1-107 B c1
Q 5001 TRANSISTOR XN1213-(TX) G3070194 108-160 Bc1
Q 5001 TRANSISTOR DMC261030L G3070445 168- B c1
Q 5002 TRANSISTOR XN1213-(TX) G3070194 1-167 B g1
Q 5002 TRANSISTOR DMC261030L G3070445 168- B g1
Q 5003 IC PST596CNR R59-2978 G1092588 1- B f2
Q 5004 TRANSISTOR XN1213-(TX) G3070194 1-107 B e2
Q 5004 TRANSISTOR 2SC4617 TL R G3346178R 108- B e2
Q 5005 IC TC7S04FU(TE85R.F) G1091530 1-107 B f1
Q 5005 TRANSISTOR XN1213-(TX) G3070194 108-160 Bf1
Q 5005 TRANSISTOR DMC261030L G3070445 168- B f1
Q 5006 TRANSISTOR DTC144EK T146 G3070033 1- B f1
Q 5007 IC HD4074829TF R0320 G1093180 1-107 A C2
Q 5007 IC LC87F7BC8A-F56G2-E G1094209 108- A C2
Q 5008 IC NM93C86AM8(TAPING) G1092512 1-57 A D1
Q 5008 IC NM93C86AM8(TAPING) G1092512 58-107 AD1
Q 5008 IC BR93L86RFVM-WTR G1094242 108- A D1
Q 5009 TRANSISTOR DTC144EK T146 G3070033 1- B e2
Q 5010 IC TC7W125FU(TE12L.F) G1092923 1- B d2
Q 5011 IC TC7W125FU(TE12L.F) G1092923 1- A D2
Q 5012 IC TC7W125FU(TE12L.F) G1092923 1- A D2
Q 5013 IC NJM78L05UA-TE1 G1091325 1- B f2
Q 5014 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5014 TRANSISTOR DMC261030L G3070445 168-
Q 5015 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5015 TRANSISTOR DMC261030L G3070445 168-
Q 5016 IC BU4094BCFV-E2 G1093527 108-
Q 5017 IC BU4094BCFV-E2 G1093527 108-
Q 5018 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5018 TRANSISTOR DMC261030L G3070445 168-
Q 5019 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5019 TRANSISTOR DMC261030L G3070445 168-
Q 5020 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5020 TRANSISTOR DMC261030L G3070445 168-
Q 5021 TRANSISTOR XN1213-(TX) G3070194 108-167
Q 5021 TRANSISTOR DMC261030L G3070445 168-
R 5001 CHIP RES. 680 1/10W 5% RMC1/10T 681J J24205681 1-107 B c1
R 5001 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 108- B c1
R 5002 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1-107 B g2
R 5002 CHIP RES. 680 1/4W 5% RMC1/4 681JATP J24245681 108- B g2
R 5003 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1-107 B g1
R 5003 CHIP RES. 680 1/4W 5% RMC1/4 681JATP J24245681 108- B g1
R 5004 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1-107 B e1
R 5005 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1-107 A D2
R 5005 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 108- A D2
R 5006 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B f2
R 5007 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1-107 B e2
R 5008 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1-107 B f1
R 5008 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 108- B f1
R 5009 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- B d1
R 5010 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D2
R 5011 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B f1
R 5012 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B f2
R 5013 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B e2
R 5014 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e2
R 5015 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
