Vertex Standard VXR-7000 Service Manual

111VXR-7000 UHF Service Manual
Display Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
R 5016 CHIP RES. 10 1W 5% RMC1 100JTE J24305100 1- B f2
R 5017 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 5018 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 108-
R 5020 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 108-
R 5021 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 108-
R 5022 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 108-
R 5023 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 108-
R 5024 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 108-
R 5025 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 108-
R 5026 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5027 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5028 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5029 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5030 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5031 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5032 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5033 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5034 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5035 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5036 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5037 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5038 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5039 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5040 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5041 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 108-
R 5044 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 108-
R 5046 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 108-
R 5047 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 108-
R 5048 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 108-
R 5049 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 108-
R 5050 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 108-
R 5051 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 108-
S 5001 TACT SWITCH EVQ-333 H=5.0(TAPE) N5090046 1- A F1
S 5002 TACT SWITCH EVQ-333 H=5.0(TAPE) N5090046 1- A F2
X 5001 XTAL HC-49/U.2S 2.4576MHz 2.4576MHZ H0103166 1-107 B e1
X 5001 XTAL U3B 7.3728MHz 7.3728MHZ H0103280 108- B e1
LCD HOLDER RA0014900 1-
LIGHT GUIDE RA0013200 1-
REFLECTOR SHEET RA0013500 1-
DIFFUSER SHEET RA0013600 1-
INTER CONNECTOR RA0013700 1-
SPONGE RUBBER R7130200 1-
LED SPACER LH-5-4 S6000237 1-
LED SPACER LH-5-2 S6000235 1-107
