144 VXR-7000 UHF Service Manual
R 0002 METAL FILM RES. 100 1W 5% ERG-1SJ101 J22305101 1- A C2
R 0003 THERMISTOR 8D-13 G9090130 1- A E1
R 0004 CARBON FILM RES. 1k 1/6W 5% RD16PJ J01225102 1- A E1
R 0005 METAL FILM RES. 100 1W 5% ERG-1SJ101 J22305101 1- A C2
R 0006 METAL FILM RES. 100k 1W 5% ERG-1SJ104 J22309049 1- A D2
R 0007 METAL FILM RES. 100k 1W 5% ERG-1SJ104 J22309049 1- A D2
R 0008 CARBON FILM RES. 1M 1/6W 5% RD16PJ105 J01225105 1- A C3
R 0009 CARBON FILM RES. 1M 1/6W 5% RD16PJ105 J01225105 1- A C3
R 0010 CARBON FILM RES. 68k 1/6W 5% RD16PJ683 J01225683 1- A C3
R 0011 CARBON FILM RES. 7.5k 1/6W 5% RD16PJ752 J01225752 1- A C2
R 0012 CARBON FILM RES. 10 1/6W 5% RD16PJ100 J01225100 1- A C1
R 0013 CARBON FILM RES. 10 1/6W 5% RD16PJ100 J01225100 1- A C1
R 0014 CARBON FILM RES. 4.7k 1/6W 5% RD16PJ472 J01225472 1- A C2
R 0015 CARBON FILM RES. 220k 1/6W 5% RD16PJ224 J01225224 1- A C3
R 0016 CARBON FILM RES. 1.2k 1/6W 5% RD16PJ122 J01225122 1- A C3
R 0017 CARBON FILM RES. 220k 1/6W 5% RD16PJ224 J01225224 1- A C1
R 0018 CARBON FILM RES. 47k 1/6W 5% RD16PJ473 J01225473 1- A C2
R 0019 CARBON FILM RES. 27k 1/6W 5% RD16PJ273 J01225273 1- A C1
R 0020 CARBON FILM RES. 3k 1/6W 5% RD16PJ302 J01225302 1- A C2
R 0021 CARBON FILM RES. 22 1/6W 5% RD16PJ220 J01225220 1- A C1
R 0022 CARBON FILM RES. 2.2 1/6W 5% RD16PJ2R2 J01225229 1- A A2
R 0023 CEMENT RES. 0.01 5W 10% MPC75 0.01 K J30379003 1- A A2
R 0024 CEMENT RES. 0.01 5W 10% MPC75 0.01 K J30379003 1- A A2
R 0025 CARBON FILM RES. 1k 1/6W 5% RD16PJ102 J01225102 1- A A2
R 0026 CARBON FILM RES. 6.8k 1/6W 5% RD16PJ682 J01225682 1- A A2
R 0027 CARBON FILM RES. 6.8k 1/6W 5% RD16PJ682 J01225682 1- A A2
R 0028 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 J01225223 1- A A2
R 0029 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 J01225223 1- A B3
R 0030 CARBON FILM RES. 100 1/6W 5% RD16PJ101 J01225101 1- A A2
R 0031 CARBON FILM RES. 100 1/6W 5% RD16PJ101 J01225101 1- A B3
R 0032 CARBON FILM RES. 3k 1/6W 5% RD16PJ302 J01225302 1- A A3
R 0033 CARBON FILM RES. 150k 1/6W 5% RD16PJ154 J01225154 1- A A2
R 0035 CARBON FILM RES. 1k 1/6W 5% RD16PJ102 J01225102 1- A A3
R 0036 CARBON FILM RES. 470 1/6W 5% RD16PJ471 J01225471 1- A A3
R 0037 CARBON FILM RES. 20k 1/6W 5% RD16PJ203 J01225203 1- A A3
R 0038 CARBON FILM RES. 22k 1/6W 5% RD16PJ223 J01225223 1- A A3
R 0039 CARBON FILM RES. 470 1/6W 5% RD16PJ471 J01225471 1- A A2
R 0040 CARBON FILM RES. 820 1/6W 5% RD16PJ821 J01225821 1- A A2
R 0041 CARBON FILM RES. 470 1/6W 5% RD16PJ471 J01225471 1- A B3
T 0001 CONVERTER TRANS. FP2017A-501 S8100822 1- A B1
T 0002 CONVERTER TRANS. FP2017A-501 S8100822 1- A B2
TERMINAL (4pcs) P91250 TAB Q5000154 1-
FUSE CLIP (2pcs) F220P P2000064 1-
AC SELECTER SK1019A-B S8100823 1-
TERMINAL (2pcs) RT-01N-2.3A Q5000153 1-
MODULE MB2013A S8100824 1-
CABLE ASSY(B) FP2017A-802 S8100825 1-
CABLE ASSY(C) FP2017A-803 S8100826 1-
CABLE ASSY(D) FP2017A-804 S8100827 1-
CABLE ASSY(E) FP2017A-805 S8100828 1-
CABLE ASSY(F) FP2017A-806 S8100829 1-
HEATSINK FP2017A-611 S8001785 1-
HEATSINK(S) FP2017A-613 S8001787 1-
FITTING A FP2017A-614 S8001788 1-
FITTING B FP2017A-615 S8001789 1-
THERMAL CONDUCTER FP2017A-701 S8001790 1-
THERMAL CONDUCTER FB419 S8001781 1-
THERMAL CONDUCTER (4pcs) TC45A-(CP-T0-3P) S8001782 1-
THERMAL CONDUCTER TC45A-(CP-T0-220) S8001783 1-
FITTING (5pcs) FR336A S8001784 1-
FITTING FR309A S8000030 1-
SPACER (5pcs) 8MM S8001794 1-
COVER FP2017A-612 S8001786 1-
PS Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
