Vertex Standard VXR-7000 Service Manual

143VXR-7000 UHF Service Manual
PS Unit
Parts List
PCB with Components Q7000303 USA (NA): 50W Type
Q7000427 Except USA (NA) & EIA (CE): 50W Type
B 0001 FERRITE BEADS B-20L-44 L9190120 1- A C2
C 0001 FILM CAP. 0.47uF 250V ECQU2A474MG K52240008 1- A D2
C 0002 FILM CAP. 0.22uF 250V ECQU2A224MG K52240007 1- A E2
C 0003 CERAMIC CAP. 0.0033uF E ECKDRS332MEY K12269003 1- A D2
C 0004 CERAMIC CAP. 0.0033uF E ECKDRS332MEY K12269003 1- A E2
C 0006 AL.ELECTRO.CAP. 1000uF 200V KMM200VNSN1000M30D K40239006 1- A D1
C 0007 AL.ELECTRO.CAP. 1000uF 200V KMM200VNSN1000M30D K40239006 1- A D2
C 0009 FILM CAP. 0.033uF 800V QXF2K333JRPT K52290001 1- A C2
C 0010 FILM CAP. 0.033uF 800V QXF2K333JRPT K52290001 1- A C1
C 0011 CERAMIC CAP. 470pF 1kV R DE0705R471K1K K10309002 1- A C1
C 0012 CERAMIC CAP. 470pF 1kV R DE0705R471K1K K10309002 1- A D1
C 0013 FILM CAP. 0.01uF 630V MMC103K-630 K52280009 1- A C1
C 0014 CERAMIC CAP. 0.001uF 1kV B ECKD3A102KBP K10309001 1- A C2
C 0016 AL.ELECTRO.CAP. 100uF 35V ECA1VHG101 K40169036 1- A C2
C 0017 AL.ELECTRO.CAP. 4.7uF 50V ECA1HHG4R7 K40179074 1- A C2
C 0018 CERAMIC CAP. 0.0033uF E ECKDRS332MEY K12269003 1- A C1
C 0021 AL.ELECTRO.CAP. 2200uF 25V EEUFC1E222 K40149063 1- A A1
C 0022 AL.ELECTRO.CAP. 2200uF 25V EEUFC1E222 K40149063 1- A A2
C 0023 AL.ELECTRO.CAP. 2200uF 25V EEUFC1E222 K40149063 1- A A1
C 0024 AL.ELECTRO.CAP. 2200uF 25V EEUFC1E222 K40149063 1- A A1
C 0025 AL.ELECTRO.CAP. 470uF 25V EEUFC1E471L K40149064 1- A A2
C 0026 AL.ELECTRO.CAP. 82uF 16V EEUFC1C820 K40129094 1- A A2
C 0027 FILM CAP. 0.01uF 630V MMC103K630 K52280009 1- A A1
C 0028 FILM CAP. 0.01uF 630V MMC103K630 K52280009 1- A A1
C 0030 FILM CAP. 0.01uF 50V ECQB1H103KF K52170021 1- A A2
C 0031 FILM CAP. 0.01uF 50V ECQB1H103KF K52170021 1- A A2
C 0032 FILM CAP. 0.1uF 50V ECQV1H104JL K52170020 1- A B3
C 0033 FILM CAP. 0.0022uF 50V ECQB1H222KF K52170022 1- A A3
C 0034 AL.ELECTRO.CAP. 0.47uF 50V ECA1HHGR47 K40179075 1- A A3
C 0035 FILM CAP. 0.1uF 50V ECQV1H104JL K52170020 1- A A3
D 0001 DIODE D10XB60 G2090753 1- A D1
D 0002 DIODE RD15EB2 G2090507 1- A C2
D 0003 DIODE P6KE400C G2090759 1- A C2
D 0005 DIODE HZ2B1 G2090755 1- A C2
D 0006 DIODE 1SS270A G2090754 1- A C2
D 0007 DIODE 1SS270A G2090754 1- A C2
D 0008 DIODE 1SS270A G2090754 1- A C2
D 0009 DIODE 1SS270A G2090754 1- A C1
D 0010 DIODE 1SS270A G2090754 1- A C1
D 0021 DIODE 1SS270A G2090754 1- A A2
D 0022 DIODE 30GWJ2C42C G2090758 1- A A1
D 0023 DIODE 30GWJ2C42C G2090758 1- A B1
D 0024 DIODE HZ15-3 G2090756 1- A A2
D 0025 DIODE HZ7A1L G2090757 1- A A2
D 0026 DIODE 1SS270A G2090754 1- A B3
D 0027 DIODE 1SS270A G2090754 1- A A3
D 0028 DIODE HZ5C1 G2090188 1- A A2
F 0001 FUSE 215005 Q0000092 1- A E2
IC0001 IC S-80745AN-D9-T1 G1092610 1- A C1
IC0021 IC NJM2904L G1093156 1- A A2
L 0001 LINE FILTER LH28V35-122 S8100821 1- A E2
L 0002 LINE FILTER LH28V35-122 S8100821 1- A E1
L 0021 RFC FL1783A S8100206 1- A A1
L 0022 RFC FL1783A S8100206 1- A
PC0001 PHOTO COUPLER PC123FY2 G0090036 1- A B3
PC0002 PHOTO COUPLER PC123FY2 G0090036 1- A B3
Q 0001 TRIAC BT138D-600 G3090129 1- A E1
Q 0002 FET 2SK1017 G3810170 1- A C1
Q 0003 FET 2SK1017 G3810170 1- A C1
Q 0004 TRANSISTOR 2SC4166-Q G3341660Q 1- A C3
Q 0005 TRANSISTOR DTC114ESA G3090130 1- A C2
Q 0006 TRANSISTOR 2SC3246H G3332460H 1- A C2
Q 0021 TRANSISTOR 2PA1015Y G3090131 1- A A2
Q 0022 TRANSISTOR 2PC1815Y G3090132 1- A B3
R 0001 CARBON FILM RES. 470k 1/2W 5% RD50SS470K J J01279001 1- A D2
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
